THROTTLE LINK & VALVE LEVER (ATM)

0001 1U660E,U660F 0002 1U760E

35056LEVER SUB-ASSY, PARKING LOCK W/ROLLER

main35057-33010iGGL1#¥720200812-201203

35501ROD SUB-ASSY, PARKING LOCK

main35501-33020iAGL10,GGL1#¥1,010200812-201203

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-33011iGGL1#¥1,860200812-201204

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iGGL1#¥160200812-201204

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35506-33011iAGL10¥1,710201008-201203

main35506-33020iGGL1#¥2,350201204

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iAGL10,GGL1#¥270200812-201203

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20006iGGL1#¥230200812-201204

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09002iAGL10,GGL1#¥100200812-201203

35556SHAFT, PARKING LOCK PAWL

main35556-33010iGGL1#¥460200812-201203

main35556-33020iAGL10¥460201008-201203

35556CSPRING, TORSION (FOR PARKING LOCK PAWL SHAFT)

main90508-21007iGGL1#¥140200812-201203

main90508-21008iAGL10¥140201008-201203

35556HSHAFT, PARKING LOCK PAWL

main35556-33030iAGL10¥220201008-201203

main35556-63010iGGL1#¥260200812-201203

35557PAWL, PARKING LOCK

main35557-33020iGGL1#¥4,460200812-201203

sub35557-33021¥3,090

main35557-33021iGGL1#¥3,090201203

main35557-73010iAGL10¥3,090201008-201203

35558CLAMP, PAWL SHAFT

main35558-33010iGGL1#¥270200812-201203

main35558-33020iAGL10¥270201008-201203

35561SHAFT, MANUAL VALVE LEVER

main35561-33020iGGL1#¥2,710200812-201204

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-33020iAGL10,GGL1#¥670200812-201509

35596PLATE, PAWL STOPPER

main35596-33010iGGL1#¥590200812-201203

main35596-73010iAGL10¥400201008-201203

35596ABOLT (FOR PAWL STOPPER PLATE)

main91551-80816iAGL10,GGL1#¥80200812-201203

35598SLEEVE, PARKING LOCK

main35598-33010iAGL10,GGL1#¥990200812-201203

8401

9155180816

main91551-80816¥80

9413000802

main94130-00802¥90

9451200800

main94512-00800¥80

22 parts on this diagram · 2 diagrams in section
