REAR SPRING & SHOCK ABSORBER

42304CARRIER SUB-ASSY, REAR AXLE, RH

main42304-50050iUCF2#199410-199707

main42304-50060iUCF20199608-200008

main42304-50080iUCF2#199707-200008

42304ABOLT (FOR REAR AXLE CARRIER)

main90119-14025iUCF2#199410

42304BNUT (FOR REAR AXLE CARRIER)

main90179-14037iUCF2#199410

42305CARRIER SUB-ASSY, REAR AXLE, LH

main42305-50050iUCF2#199410-199707

main42305-50060iUCF20199608-200008

main42305-50080iUCF2#199707-200008

48080CYLINDER ASSY, PNEUMATIC, REAR RH W/SHOCK ABSORBER

main48080-50100iUCF21199707

main48080-59015iUCF21199410-199707

sub48080-50090

48090CYLINDER ASSY, PNEUMATIC, REAR LH W/SHOCK ABSORBER

main48090-50100iUCF21199707

main48090-59015iUCF21199410-199707

sub48090-50090

48190RCAM ASSY, CAMBER ADJUST

main48190-22030iUCF2#199410

48198RCAM, REAR SUSPENSION CAMBER ADJUST, NO.2

main48198-22020iUCF2#199410

48231ASPRING, COIL, REAR RH

main48231-50090iUCF20199608-199707

main48231-50100iUCF20199410-199608

main48231-50101iUCF20199608-199707

sub48231-50100

main48231-50120iUCF20199707-200008

main48231-50130iUCF20199707-200008

48231BSPRING, COIL, REAR LH

main48231-50090iUCF20199608-199707

main48231-50100iUCF20199410-199608

main48231-50101iUCF20199608-199707

sub48231-50100

main48231-50120iUCF20199707-200008

main48231-50130iUCF20199707-200008

48257BINSULATOR, REAR COIL SPRING, UPPER

main48257-50010iUCF20199410

48341BUMPER, REAR SPRING

main48341-50010iUCF20199410-199707

main48341-50050iUCF20199707

48530ABSORBER ASSY, SHOCK, REAR RH

main48530-59095iUCF20199410-199707

sub48530-59096

main48530-59105iUCF20199608-199707

sub48530-59106

main48530-59115iUCF20199707-200008

sub48530-59097

main48530-59125iUCF20199707-200008

sub48530-59126

48540ABSORBER ASSY, SHOCK, REAR LH

main48530-59095iUCF20199410-199707

sub48530-59096

main48530-59105iUCF20199608-199707

sub48530-59106

main48530-59115iUCF20199707-200008

sub48530-59097

main48530-59125iUCF20199707-200008

sub48530-59126

48553DCAP, REAR SHOCK ABSORBER, RH

main48553-50070iUCF21199410

main48553-50080iUCF20199410

48554ACAP, REAR SHOCK ABSORBER, LH

main48553-50080iUCF20199410

main48554-50040iUCF21199410

48703CNUT(FOR REAR SUSPENSION ARM)

main90179-12027iUCF2#199410

48710AARM ASSY, REAR SUSPENSION, NO.1 RH

main48710-50030iUCF20199410-199707

sub48710-50050

main48710-50040iUCF21199410-199707

main48710-50050iUCF2#199707

48720AARM ASSY, REAR SUSPENSION, NO.1 LH

main48710-50030iUCF20199410-199707

sub48710-50050

main48720-50020iUCF21199410-199707

main48720-50030iUCF2#199707

48724DAMPER, LWR CONTROL ARM DYNAMIC

main48724-50011iUCF2#199508

48730AARM ASSY, REAR SUSPENSION, NO.2

main48730-50020iUCF2#199410-199605

sub48730-50021

main48730-50021iUCF2#199605-200008

main48730-50031iUCF20199608-200008

48750ANUT(FOR REAR SUPPORT TO REAR SHOCK ABSORBER)

main90177-12002iUCF20200003

main94187-11200iUCF20199410-200003

sub90177-12002

48750GNUT(FOR REAR SUSPENSION SUPPORT)

main90179-10088iUCF2#199410

48755SUPPORT, REAR SUSPENSION

main48755-50080iUCF20199410-199707

main48755-50090iUCF20199707

48770AARM ASSY, UPPER CONTROL, REAR RH

main48770-59015iUCF2#199410-200008

main48770-59025iUCF20199608-200008

48780AROD ASSY, STRUT, REAR

main48780-50020iUCF2#199410-199707

main48780-50021iUCF2#199707

48790ARM ASSY, UPPER CONTROL, REAR LH

main48790-59015iUCF2#199410-200008

main48790-59025iUCF20199608-200008

48812BAR, STABILIZER, REAR

main48812-40070iUCF20199707-200008

main48812-50070iUCF20199608-199707

main48812-50080iUCF2#199410-199707

main48812-50100iUCF2#199707-200008

48815RBUSH, STABILIZER(FOR REAR)

main48815-40060iUCF20199707-200008

main48815-50130iUCF20199608-199707

main48815-50140iUCF2#199410-199707

main48815-50160iUCF2#199707-200008

48824RBRACKET, STABILIZER(FOR REAR)

main48824-22060iUCF2#199410-199508

main48824-50030iUCF2#199508

48830LINK ASSY, REAR STABILIZER

main48830-22040iUCF2#199410-199509

sub48830-22041

main48830-22041iUCF2#199509

48830ANUT(FOR REAR STABILIZER LINK)

main90179-12052iUCF2#199410

9010512277

main90105-12277

9011908661

main90119-08661

9011912284

main90119-12284

9011914035

main90119-14035

9011914040

main90119-14040

9017012038

main90170-12038

9017014012

main90170-14012

9017908184

main90179-08184

9017912137

main90179-12137

9017912138

main90179-12138

9017914015

main90179-14015

9017914045

main90179-14045

9020112071

main90201-12071

9020114020

main90201-14020

9411041000

main94110-41000

9413061000

main94130-61000

48 parts on this diagram · 1 diagram in section
