THROTTLE LINK & VALVE LEVER (ATM)

35056LEVER SUB-ASSY, PARKING LOCK W/ROLLER

main35057-33010iGGA10200709-201310

35501ROD SUB-ASSY, PARKING LOCK

main35501-33020iGGA10200709-201310

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-33010iGGA10..CBU200709-200810

sub35505-33011

main35505-33011iGGA10200810-201204

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iGGA10200709-201310

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35506-33020iGGA10..CBU201204-201310

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iGGA10200709-201310

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20006iGGA10200709-201310

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09002iGGA10200709-201310

35556SHAFT, PARKING LOCK PAWL

main35556-33010iGGA10200709-201310

35556CSPRING, TORSION (FOR PARKING LOCK PAWL SHAFT)

main90508-21007iGGA10200709-201310

35556HSHAFT, PARKING LOCK PAWL

main35556-63010iGGA10200709-201310

35557PAWL, PARKING LOCK

main35557-33020iGGA10200709-201203

sub35557-33021

main35557-33021iGGA10..CBU201203-201310

35558CLAMP, PAWL SHAFT

main35558-33010iGGA10200709-201310

35561SHAFT, MANUAL VALVE LEVER

main35561-33020iGGA10200709-201204

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-33020iGGA10..CBU200709-201310

35596PLATE, PAWL STOPPER

main35596-33010iGGA10200709-201310

35596ABOLT (FOR PAWL STOPPER PLATE)

main91551-80816iGGA10200709-201310

35598SLEEVE, PARKING LOCK

main35598-33010iGGA10200709-201310

8401

9155180816

main91551-80816

9413000802

main94130-00802

9451200800

main94512-00800

22 parts on this diagram · 1 diagram in section
