REAR SPRING & SHOCK ABSORBER
48351BUMPER, DIFFERENTIAL CARRIER
48702BUSH SUB-ASSY, UPPER CONTROL ARM
48702CBUSH SUB-ASSY, LOWER CONTROL ARM
48706ABUSH SUB-ASSY, REAR LATERAL CONTROL ROD
48710ARM ASSY, UPPER CONTROL
48715ABOLT, HEXAGON(FOR UPPER CONTROL ARM)
L=163
L=95
48720ARM ASSY, LOWER CONTROL, RH
48724DAMPER, LWR CONTROL ARM DYNAMIC
48725ABOLT(FOR LOWER CONTROL ARM)
48730ARM ASSY, LOWER CONTROL, LH
48740ROD ASSY, REAR LATERAL CONTROL
48745BUSH, LATERAL CONTROL ROD
48745ABOLT, HEXAGON(FOR LATERAL CONTROL ROD)
48802LINK SUB-ASSY, STABILIZER
48802DBUSH, STABILIZER LINK
48802ESPACER(FOR REAR STABILIZER BAR)
48812BAR, STABILIZER, REAR
48817RCUSHION, STABILIZER(FOR REAR)
48817SRETAINER, CUSHION, NO.1(FOR STABILIZER REAR BAR)
48817UBOLT(FOR REAR STABILIZER)
48824RBRACKET, STABILIZER(FOR REAR)
48832RBRACKET, REAR STABILIZER BAR, NO.1 RH
48833RBRACKET, REAR STABILIZER BAR, NO.1 LH
6161560816TROUGH, LUGGAGE COMPARTMENT OPENING, RH
main61615-60816
9011912066
main90119-12066
9161160816
main91611-60816
9161260820
main91612-60820
9414141000
main94141-41000
9418210800
main94182-10800
9418401600
main94184-01600
9451201600
main94512-01600
9461212000
main94612-12000
9461311600
main94613-11600
9538102525
main95381-02525
35 parts on this diagram · 2 diagrams in section
