THROTTLE LINK & VALVE LEVER (ATM)

0001 1A42D,A42DE,A43D 0002 1A43D 0003 1A43D 0004 1A43D 0005 1A42D 0006 1A42D 0007 1A340E

35501ROD SUB-ASSY, PARKING LOCK

main35501-22020iSXS13..4FC199604-200708

main35501-26020iYXS10..CRW..4HC199512-200706

main35501-60010iTSS1#..4FC200210

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-22040iGXS10199512-200210

main35505-22050iYXS10..SED..4HC199512-200708

main35505-50020iTSS1#..4FC200210

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iGXS10199512-200708

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-11003iSXS13..4FC199512-200708

main90311-12002iTSS1#..4FC200210

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20003iGXS10,LXS11,SXS11,YXS1#..ATM199512-200302

sub90560-20025

main90560-20006iGBS12200210-200302

main90560-20025iGBS12,YXS1#..4FC200302-200708

35556SHAFT, PARKING LOCK PAWL

main35556-26010iYXS10..CRW..4HC199512-200707

main35556-30020iTSS1#..4FC200210

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iTSS1#..4FC199512-200708

35557PAWL, PARKING LOCK

main35557-26020iYXS11..4FC;GXS10,LXS11,YXS10..(CRW,TAX)..ATM199512-200706

main35557-35010iLXS11,SXS11..4FC..DLX199604-200708

main35557-60020iGBS12200210

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21001iYXS10..CRW..4HC199512-200706

main90508-21002iGBS12200210

main90508-25001iLXS11,SXS11..4FC..DLX199604-200708

35561SHAFT, MANUAL VALVE LEVER

main35561-30070iTSS1#..4FC200709-201801

main35561-35010iGBS12200210

main35561-40010iYXS10..SED..4HC199512-200708

35572LEVER, TRANSMISSION CONTROL SHAFT, RH

main35572-22040iYXS1#..4FC199512-200708

main35572-30060iTSS1#..4FC200210

35595BRACKET, PARKING LOCK PAWL

main35595-40010iGXS10199512-200708

main35595-60010iGBS12200210

9010106024

main90101-06024

9411050800

main94110-50800

9451200800

main94512-00800

9454200600

main94542-00600

16 parts on this diagram · 7 diagrams in section
