THROTTLE LINK & VALVE LEVER (ATM)

0001 1A960E 0002 1A760H 0003 1AA81E 0004 1AA81E

3312

35501ROD SUB-ASSY, PARKING LOCK

main35501-30050iGRS211201212-201509

main35501-30060iGRS210201212-201509

main35501-50020iGRS214201212-201509

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-30040iGRS214201212-201509

main35505-53030iGRS211201509-201804

main35505-53040iGRS210201212-201509

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iARS210,GRS21#201509-201804

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iGRS210,211201212-201509

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20025iGRS21#201212-201509

35556SHAFT, PARKING LOCK PAWL

main35556-60020iGRS21#201212-201509

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iARS210,GRS21#201509-201804

35557PAWL, PARKING LOCK

main35557-30050iGRS210,211201509-201804

main35590-50020iARS210,GRS214201509-201804

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90949-03130iGRS211201212-201509

main90949-03137iGRS210201212-201509

35561SHAFT, MANUAL VALVE LEVER

main35561-50020iGRS210201509-201804

main35561-50030iARS210,GRS214201509-201804

main35561-60030iGRS211201212-201509

35572LEVER, TRANSMISSION CONTROL SHAFT, RH

main35572-30070iGRS210201509-201804

main35572-30100iARS210,GRS214201509-201804

35595BRACKET, PARKING LOCK PAWL

main35595-50010iGRS210,211201212-201509

main35595-50020iGRS214201212-201509

8401

91611B0614

main91611-B0614

9413000802

main94130-00802

9451200800

main94512-00800

17 parts on this diagram · 4 diagrams in section
