THROTTLE LINK & VALVE LEVER (ATM)

0001 1A42DE 0002 1A340H 0003 1A340E,A343E 0004 1A650E

35501ROD SUB-ASSY, PARKING LOCK

main35501-26020iGX110200106-200404

main35501-30020iJZX110..5FC200106-200404

main35501-60010iGX115,JZX110..4FC200106-200404

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-22070iGX110200106-200404

main35505-50020iGX115,JZX110..ATM200106-200404

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iGX11#,JZX110..ATM200106-200404

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-11003iGX110200106-200404

main90311-12002iGX115,JZX110..ATM200106-200404

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20003iGX110200106-200302

sub90560-20025

main90560-20006iGX115,JZX110..ATM200106-200302

main90560-20025iGX11#,JZX110..ATM200302-200404

35556SHAFT, PARKING LOCK PAWL

main35556-26010iGX110200106-200404

main35556-30020iGX115,JZX110..4FC200106-200404

main35556-30030iJZX110..5FC200106-200404

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iGX11#,JZX110..ATM200106-200404

35557PAWL, PARKING LOCK

main35557-35010iGX110200106-200404

main35557-60020iGX115,JZX110..4FC200106-200404

main35590-30010iJZX110..5FC200106-200404

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21002iGX115,JZX110..4FC200106-200404

main90508-25001iGX110200106-200404

main90949-03065iJZX110..5FC200106-200404

35561SHAFT, MANUAL VALVE LEVER

main35561-22030iGX110200106-200404

main35561-30070iJZX110..ATM200106-200404

main35561-35010iGX115200106-200404

35572LEVER, TRANSMISSION CONTROL SHAFT, RH

main35572-22050iGX110200106-200404

main35572-30080iJZX110..ATM200106-200404

35595BRACKET, PARKING LOCK PAWL

main35595-30020iJZX110..5FC200106-200404

main35595-40010iGX110200106-200404

main35595-60010iGX115,JZX110..4FC200106-200404

8401

9010106024

main90101-06024

9411050800

main94110-50800

9451200800

main94512-00800

9454200600

main94542-00600

17 parts on this diagram · 4 diagrams in section
