REAR DISC BRAKE CALIPER & DUST COVER

0001 1 0002 1

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-22030iGX81,JZX81,MX83..SPC,TWC,TWT198808-199210

main04479-22040iGX81..HTWC198808-199210

04492PAD KIT, DISC BRAKE, REAR

main04492-22080iGX81..SPC,TWC,TWT198808-198908

sub04492-22090

main04492-22090iGX81,MX83..SPC,TWC,TWT198908-199002

sub04466-22090

main04492-22100iGX81..HTWC198808-198908

sub04492-22101

main04492-22101iGX81..HTWC198908-199002

sub04466-22090

main04492-22110iGX81,MX83..SPC,TWC,TWT199002-199008

sub04492-22111

main04492-22120iGX81..HTWC199002-199204

sub04492-22121

main04492-22121iGX81..HTWC199204-199210

sub04466-22040

main04492-22140iGX81,JZX81,MX83..TWC,TWT199008-199210

sub04492-22141

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010iGX81,JZX81,MX83198808-199210

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-35020iGX81,JZX81,MX83198808-199210

47716APLATE, PAD SUPPORT, NO.1(FOR REAR DISC BRAKE)

main47716-22020iGX81..HTWC198808-199210

main47716-40020iGX81,JZX81,MX83..SPC,TWC,TWT198808-199210

47721CMOUNTING, REAR DISC BRAKE CYLINDER, RH

main47721-22100iGX81,JZX81,MX83..SPC,TWC,TWT198808-199210

main47721-22110iGX81..HTWC198808-199210

47721DBOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)

main90119-09015iGX81,JZX81,MX83198808-199210

main90119-09016iGX81,JZX81,MX83198808-199210

47722AMOUNTING, REAR DISC BRAKE CYLINDER, LH

main47721-22100iGX81,JZX81,MX83..SPC,TWC,TWT198808-199210

main47721-22110iGX81..HTWC198808-199210

47730BCYLINDER ASSY, REAR DISC BRAKE, RH

main47730-22200iGX81,JZX81,MX83..SPC,TWC,TWT198808-199210

main47730-22210iGX81..HTWC198808-199210

sub47730-22211

47731BPISTON, REAR DISC BRAKE

main47731-22020iGX81,JZX81,MX83..SPC,TWC,TWT198808-199210

main47731-22030iGX81..HTWC198808-199210

47744CSHIM, ANTI-SQUEAL, NO.1(FOR REAR DISC BRAKE)

main47744-22100iGX81,JZX81,MX83198808-199210

47745BSHIM, ANTI-SQUEAL, NO.2(FOR REAR DISC BRAKE)

main47745-22060iGX81,JZX81,MX83198808-199210

47750ACYLINDER ASSY, DISC BRAKE, REAR LH

main47750-22200iGX81,JZX81,MX83..SPC,TWC,TWT198808-199210

main47750-22210iGX81..HTWC198808-199210

sub47750-22211

47769ABUSH, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47769-22020iGX81,JZX81,MX83198808-199210

47771APLATE, PAD WEAR INDICATOR(FOR REAR DISC BRAKE)

main47771-22040iGX81,JZX81,MX83198906-199210

47779ABUSH, CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)

main47779-22010iGX81,JZX81,MX83198808-199210

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90119-10206iGX81,JZX81,MX83198808-199210

17 parts on this diagram · 2 diagrams in section
