FRONT BUMPER & BUMPER STAY

0001 1��(P.P. �����) 0002 1��(���� �����) 0003 1��(���� �����)

52011AARM SUB-ASSY, FRONT BUMPER, RH

main52011-22220iLX80,YX80..DSL,LPG;LX80,SX80..(KYO,STD)..(CI,HTWC,TD)198808-199512

52012AARM SUB-ASSY, FRONT BUMPER, LH

main52012-22210iLX80,YX80..DSL,LPG;LX80,SX80..(KYO,STD)..(CI,HTWC,TD)198808-199512

52115ASUPPORT, FRONT BUMPER SIDE, RH

main52115-22140iYX80;LX80,SX80..KYO,STD198808-199008

main52115-22140iGX81,LX80,MX83,SX80..SED..(GD,GDG,GL,GR,LG)198808-199008

main52115-22150iLX80,YX80;SX80..KYO199302-199512

main52115-22150iYX80;LX80,SX80..KYO,STD198808-199302

main52115-22160iGX81,JZX81,LX80,MX83,SX80..GD,GDG,GL,GR,GT,LG199008-199512

main52115-22160iGX81,LX80,MX83..HT198808-199512

52116ASUPPORT, FRONT BUMPER SIDE, LH

main52115-22150iLX80,YX80;SX80..KYO199302-199512

main52115-22150iYX80;LX80,SX80..KYO,STD198808-199302

main52116-22120iSX80..STD198808-199008

main52116-22120iGX81,LX80,MX83,SX80..SED..(GD,GDG,GL,GR,LG)198808-199008

main52116-22130iSX80..STD199008-199512

main52116-22130iGX81,LX80,MX83..HT198808-199512

52119ACOVER, FRONT BUMPER

main52119-22360iLX80,YX80..DSL,LPG;LX80,SX80..(KYO,STD)..(HTWC,TD)199008-199512

main52119-22370-04iYX80..GL199008-199302

BLUE M,869

sub52119-22922

main52119-22370-05iGX81,LX80,SX80..SED..(GD,GR)199008-199302

sub52119-22922

main52119-22370-07iGX81,LX80,SX80..SED..(GD,GL,GR,LG)199008-199302

DARK GRAISH GREEN M,6L8

sub52119-22922

main52119-22370-08iYX80;LX80,SX80..KYO199008-199302

SUPER WHITE 4,050

sub52119-22922

main52119-22370-08iSX80,YX80..KYO199302-199305

SUPER WHITE 4,SUPER WHITE 4,050

sub52119-22922

main52119-22370-12iYX80..GL199008-199302

DARK MAUVE MICA,3K1

sub52119-22922

main52119-22370-13iLX80,YX80..GL199008-199512

DARK BLUISH GRAY M,183

sub52119-22922

main52119-22370-A0iLX80,YX80;SX80..KYO199302-199512

SUPER WHITE 2,040

sub52119-22922

main52119-22370-B0iGX81,SX80..GD,GL,GR199409-199512

SILVER ME.,199

sub52119-22922

main52119-22370-E0iLX80,YX80..GL199302-199512

FLAXEN MICA M.,4M7

sub52119-22922

main52119-22370-G0iLX80,YX80..GL199302-199409

DK.GRAYISH OLIVE M.,6M7

sub52119-22922

main52119-22380-05iGX81..SED..GD199008-199302

main52119-22380-07iGX81..SED..TWC199008-199210

D GRISH GREN M/BLK M,TRIM1#,3#,4#&6L8

main52119-22380-08iJZX81,MX83..SED199008-199210

WHITE P/MC / SLVR M,049

main52119-22380-12iGX81..SED..TWC199008-199210

D MAUVE MICA/BLACK M,TRIM1#,3#,4#&3K1

main52119-22380-13iJZX81,MX83..SED199008-199210

BLUISH GRY M/BLCK M,182

main52119-22380-14iGX81..SED..TWC199008-199210

BLUE M/BLACK M,TRIM1#,3#,4#&869

main52119-22380-18iJZX81,MX83..SED199008-199302

SPR WHITE 4/SILVER M,TRIM1#,3#,4#&050

main52119-22380-23iJZX81,MX83199210-199302

D BLISH GRY M/BLCK M,TRIM1#,3#&183

main52119-22380-23iJZX81,MX83..SED199008-199210

D BLISH GRY M/BLCK M,TRIM1#,3#,4#&183

main52119-22380-A0iGX81,SX80..GD,GR199302-199512

SPR WHITE 2/SILVER M,040

main52119-22380-B0iGX81,SX80..GD,GL,GR199409-199512

SILVER ME./GRAY M.M,199

main52119-22380-E0iGX81,SX80..GD,GR199302-199512

FLAXEN M. M/GRAY M.M,4M7

main52119-22540-02iGX81,LX80,SX80..SED..(GD,GL,GR,LG)198808-198908

DARK RED MICA,3H3,TYPEA

sub52119-22917

main52119-22540-03iYX80..GL198808-199008

MIST GRAY M,177,TYPEA

sub52119-22917

main52119-22540-04iGX81,LX80,SX80..SED..(GD,GL,GR,LG)198808-199008

BLUE MICA,8E3,TYPEA

sub52119-22917

main52119-22540-08iYX80;LX80,SX80..KYO198808-199008

SUPER WHITE 4,050,TYPEA

sub52119-22917

main52119-22540-13iGX81,LX80,SX80..SED..(GD,GL,GR,LG)198808-199008

GRAY MICA M,170,TYPEA

sub52119-22917

main52119-22540-33iGX81,LX80,MX83,SX80..SED..(GD,GDG,GL,GR,LG)198908-199008

GREENISH SILVER M,174,TYPEA

sub52119-22917

main52119-22540-43iGX81,LX80,MX83,SX80..SED..(GD,GDG,GL,GR,LG)198908-199008

DARK BLUEISH GRAY M,183,TYPEA

sub52119-22917

main52119-22550iLX80,YX80..DSL,LPG;LX80,SX80..(KYO,STD)..(CI,TD)198808-199008

sub52119-22917

main52119-22560-02iGX81..SED..GD198808-198908

sub52119-22936

main52119-22560-03iGX81..SED..GD198808-199008

sub52119-22936

main52119-22560-04iGX81,MX83..SED..(GD,GDG)198808-199008

sub52119-22936

main52119-22560-08iGX81,MX83..SED..(GD,GDG)198808-199008

sub52119-22936

main52119-22560-13iGX81,MX83..SED..(GD,GDG)198808-199008

sub52119-22936

main52119-22560-33iGX81,MX83..SED..(GD,GDG)198908-199008

sub52119-22936

main52119-22560-43iGX81,MX83..SED..(GD,GDG)198908-199008

sub52119-22936

main52119-22570-02iGX81..HT..(HTWC,TWC,TWT)198808-198908

sub52119-22750

main52119-22570-03iGX81,LX80..HT..(HTWC,TD,TWC,TWT)198808-199008

sub52119-22750

main52119-22570-04iGX81,LX80,MX83..HT198808-199008

sub52119-22750

main52119-22570-07iGX81,LX80,SX80..HT199008-199210

sub52119-22750

main52119-22570-08iGX81,LX80,MX83..HT198808-199210

sub52119-22750

main52119-22570-12iGX81,LX80,SX80..HT199008-199210

sub52119-22750

main52119-22570-13iGX81..HT..(HTWC,TWC,TWT)198808-199008

sub52119-22750

main52119-22570-14iGX81,LX80,SX80..HT199008-199210

sub52119-22750

main52119-22570-33iGX81,LX80,MX83..HT..(HTWC,SPC,TD,TWC)198908-199008

sub52119-22750

main52119-22570-33iGX81,LX80,MX83..HT..(HTWC,SPC,TD,TWC)198908-199008

TYPE A,GREENISIH SILVER M,GREENISIH SILVER M,174

sub52119-22750

main52119-22570-43iGX81..TWT198908-199210

TYPE A,DARK BLUEISH GRAY M,DARK BLUEISH GRAY M,183

sub52119-22750

main52119-22570-43iGX81,LX80,MX83..HT..(HTWC,SPC,TD,TWC)198908-199210

sub52119-22750

main52119-22590-03iGX81..HT..(GD,GT)198808-199008

sub52119-22943

main52119-22590-04iGX81,MX83..HT..(GD,GDG,GT)198808-199008

sub52119-22943

main52119-22590-07iGX81..HT..GD199008-199210

sub52119-22943

main52119-22590-08iGX81..HT..(GD,GDG,GT)198808-199210

sub52119-22943

main52119-22590-12iGX81..HT..GD199008-199210

sub52119-22943

main52119-22590-13iGX81,MX83..HT..(GD,GDG,GT)198808-199008

sub52119-22943

main52119-22590-14iGX81..HT..GD199008-199210

sub52119-22943

main52119-22590-33iGX81,MX83..HT..(GD,GDG,GT)198908-199008

sub52119-22943

main52119-22590-43iGX81..HT..GD198908-199210

sub52119-22943

main52119-22630iYX80;LX80,SX80..KYO,STD198808-199512

main52119-22660-03iGX81,MX83..SED..GDG198808-199008

GRAY M M-M BROWN M,170,TYPEB

sub52119-22917

main52119-22660-08iGX81..SED..SPC198808-198901

S WHITE 4-S SILVER M,050,TYPEB

sub52119-22917

main52119-22660-13iGX81,MX83..SED..GDG198908-199008

GREENISH SILVER M,174,TYPEB

sub52119-22917

main52119-22660-18iGX81..SED..SPC198808-198901

WHITE PEARL MICA,049,TYPEB

sub52119-22917

main52119-22660-28iGX81,MX83..SED..GDG198902-199008

S WHITE 4-SILVER M,050,TYPEB

sub52119-22917

main52119-22660-38iGX81,MX83..SED..GDG198902-199008

WHITE P M-SILVER M,049,TYPEB

sub52119-22917

main52119-22670-03iGX81,MX83..SED..GDG198808-199008

sub52119-22936

main52119-22670-08iGX81..SED..SPC198808-198901

sub52119-22936

main52119-22670-13iGX81,MX83..SED..GDG198908-199008

sub52119-22936

main52119-22670-18iGX81..SED..SPC198808-198901

sub52119-22936

main52119-22670-28iGX81,MX83..SED..GDG198902-199008

sub52119-22936

main52119-22670-38iGX81,MX83..SED..GDG198902-199008

sub52119-22936

main52119-22680-03iGX81..HT..(GD,GT)198808-199008

sub52119-22750

sub52119-22680

main52119-22680-05iLX80,SX80..HT199008-199210

sub52119-22750

sub52119-22680

main52119-22680-08iGX81..HT..SPC198808-198901

S WHITE 4-S SILVER M,050,TYPEB

sub52119-22750

sub52119-22680

main52119-22680-13iGX81..HT..(GD,GT)198908-199008

sub52119-22750

sub52119-22680

main52119-22680-18iGX81..HT..SPC198808-198901

WHITE PEARL MICA,049,TYPEB

sub52119-22750

sub52119-22680

main52119-22680-28iGX81..HT..GD198808-199210

sub52119-22750

sub52119-22680

main52119-22680-38iGX81..TWT198902-199210

sub52119-22750

sub52119-22680

main52119-22680-48iGX81..HT..GD..HTWC199004-199008

sub52119-22750

sub52119-22680

main52119-22680-48iGX81,MX83..HT..GDG198902-199008

sub52119-22750

sub52119-22680

main52119-22680-A0iGX81..HT..GD..HTWC199109-199110

sub52119-22750

sub52119-22680

main52119-22680-A0iGX81..HT..4FC..GD..HTWC199112-199210

sub52119-22750

sub52119-22680

main52119-22680-A1iGX81..HT..4FC..GD..HTWC199112-199210

sub52119-22750

sub52119-22680

main52119-22690-03iGX81,MX83..HT..GDG198808-199008

sub52119-22943

main52119-22690-05iGX81..HT..GD199008-199210

sub52119-22943

main52119-22690-08iGX81..HT..SPC198808-198901

sub52119-22943

main52119-22690-13iGX81,MX83..HT..GDG198908-199008

sub52119-22943

main52119-22690-18iGX81..HT..SPC198808-198901

sub52119-22943

main52119-22690-28iGX81..HT..(GD,GT)198808-199210

sub52119-22943

main52119-22690-38iGX81,MX83..HT..GDG198902-199210

sub52119-22943

main52119-22690-48iGX81,MX83..HT..GDG198902-199008

sub52119-22943

main52119-22700-02iGX81,JZX81,MX83..SED..(GD,GDG)199008-199210

main52119-22700-03iJZX81,MX83..SED199008-199210

main52119-22700-04iGX81,JZX81,MX83..SED..(GD,GDG)199008-199210

main52119-22700-05iGX81,JZX81,MX83..SED..(GD,GDG)199008-199210

main52119-22700-07iGX81,JZX81,MX83..SED..(GD,GDG)199008-199210

main52119-22700-08iJZX81,MX83..SED199008-199210

main52119-22700-13iGX81,JZX81,MX83..SED..(GD,GDG)199008-199302

main52119-22700-18iGX81,JZX81,MX83..SED..(GD,GDG)199008-199210

main52119-22730-01iJZX81,MX83..HT199008-199210

EXCELLENT TONNING,24S

main52119-22730-02iJZX81,MX83..HT199008-199210

D MAUVE MICA/BLACK M,3K1

main52119-22730-03iJZX81,MX83..HT..TWC199008-199210

BLUISH GRY/BLACK M,182

main52119-22730-04iJZX81,MX83..HT199008-199210

BLUE M/BRACK M,869

main52119-22730-05iJZX81,MX83..HT199008-199210

BEIGE M.M/GRAY M.M,4J1

main52119-22730-07iJZX81,MX83..HT199008-199210

D GRISH GREN M/BLK M,6L8

main52119-22730-08iJZX81,MX83..HT199008-199210

WHITE P/MC / SLVR M,049

main52119-22730-08iJZX81..HT..GD199105

main52119-22730-13iJZX81,MX83..HT199008-199210

D BLISH GRY M/BLCK M,183

main52119-22730-18iJZX81,MX83..HT199008-199210

SUPER WHITE 4/SLVR M,050

main52119-22730-28iJZX81,MX83..HT199008-199210

PEARL STREAM TONNING,22K

main52119-22740-01iJZX81,MX83..HT199008-199210

main52119-22740-02iJZX81,MX83..HT199008-199210

main52119-22740-03iJZX81,MX83..HT..TWC199008-199210

main52119-22740-04iJZX81,MX83..HT199008-199210

main52119-22740-05iJZX81,MX83..HT199008-199210

main52119-22740-07iJZX81,MX83..HT199008-199210

main52119-22740-08iJZX81,MX83..HT..GDG199008-199210

main52119-22740-13iJZX81,MX83..HT199008-199210

main52119-22740-18iJZX81,MX83..HT199008-199210

main52119-22740-28iJZX81,MX83..HT199008-199210

main52119-22922iLX80,SX80..SED..GR199008-199512

52526RETAINER, FRONT BUMPER, LOWER SIDE

main52526-22060iGX81,LX80,SX80..HT198808-199210

main52526-22070iJZX81,MX83;GX81,LX80,SX80,YX80..SED199008-199512

52526ARETAINER, FRONT BUMPER, LOWER NO.1

main52565-12040iLX80,YX80..DSL,LPG;LX80,SX80..(KYO,STD)..(CI,HTWC,TD)198808-199512

9011908536

main90119-08536

9011910192

main90119-10192

9015960213

main90159-60213

9016350006

main90163-50006

9017906086

main90179-06086

9046705067

main90467-05067

904670703001

main90467-0703001

14 parts on this diagram · 3 diagrams in section
