OIL COOLER & TUBE (ATM)

0001 1A541E 0003 1U140E 0004 1U140E,AIR COOLING OIL COOLER

32921TUBE, OIL COOLER INLET, NO.1

main32921-33070iMCV21199608-199808

main32921-33090iMCV20199808

32921CUNION(FOR OIL COOLER TUBE)

main32901-32050iMCV2#199608-199808

main90404-16021iMCV20199808-199908

main90404-16031iMCV2#199608-199908

main90407-16010iMCV20199808

32921DHOSE(FOR OIL COOLER INLET)

main32941-33040iMCV21199608-199808

main90445-17128iMCV20199808

32921GRING, O(FOR OIL COOLER TUBE UNION)

main90301-10189iMCV2#199608

32922TUBE, OIL COOLER OUTLET, NO.1

main32922-33060iMCV2#199608-199808

main32922-33070iMCV20199808

32922AHOSE(FOR OIL COOLER OUTLET)

main90445-17106iMCV2#199608-199808

main90445-17155iMCV20199808

32924ACLAMP(FOR OIL COOLER TUBE, NO.2)

main90462-12074iMCV2#199608-199808

32926CUSHION, OIL COOLER TUBE(ATM)

main32926-30020iMCV2#199608

9046716013

main90467-16013

9161160612

main91611-60612

10 parts on this diagram · 3 diagrams in section
