CAUTION PLATE & NAME PLATE (ENGINE)

11283PLATE, TURBOCHARGER CAUTION

main11294-64040i3CT..CV4#199406-199708

sub11294-64070

main11294-64070i3CT..CV4#199708

11289PLATE, SPARK PLUG CAUTION

main11289-62020i3SFE,4SFE..SV4#199605

11292PLATE, ENGINE NAME, NO.2

main11292-64060i3CT..CV40199406-199408

main11292-74101i3SFE..SV41,42,43199406-199605

main11292-74130i4SFE..SV40199406-199605

11296ALABEL, ENGINE SERVICE INFORMATION

main11296-64010i3CT..CV4#199406

main11296-74160i3SFE,4SFE..SV4#199406-199504

sub11296-74161

main11296-74161i3SFE,4SFE..SV4#199504-199605

main11296-74170i3SFE,4SFE..SV4#199605

15369PLATE, ENGINE OIL CAUTION

main15369-54010i3CT..CV4#199406-199708

main15369-64010i3CT..CV4#199708

16701GLABEL, CAUTION

main88723-12100i3SFE,4SFE..SV4#199406-199702

main88723-20081i3SFE,4SFE..SV4#199702

sub16793-31070

17700DPLATE, ENGINE CAUTION

main11296-55020i3CT..CV4#199406-199505

main11296-64020i3CT..CV4#199505

17791LABEL, MAINTENANCE INFORMATION

main17791-55010i3CT..CV4#199406

main17791-74040i3SFE,4SFE..SV4#199406

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

9 parts on this diagram · 1 diagram in section
