THROTTLE LINK & VALVE LEVER (ATM)

0001 1U151E,U241E 0003 1A248F

35501ROD SUB-ASSY, PARKING LOCK

main35501-12030iAZT255200606

main35501-21010iAZT250,251200307-200606

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-12100iAZT255200606

main35505-21010iAZT250,251200606

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20006iAZT25#200307-200606

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iAZT25#200307-200606

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iAZT25#200307-200606

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iAZT250,251200307-200606

main90524-11001iAZT255200606

35556SHAFT, PARKING LOCK PAWL

main35556-12020iAZT255200606

main35556-28010iAZT251200506-200606

main35556-32030iAZT250200606

35557PAWL, PARKING LOCK

main35557-12030iAZT255200606

main35590-21010iAZT251200506-200606

main35590-32010iAZT250200307-200606

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90506-18077iAZT250,251200307-200606

main90949-03060iAZT255200606

35558CLAMP, PAWL SHAFT

main35558-12010iAZT255200309-200606

main35558-28010iAZT251200506-200606

main35558-32010iAZT250200307-200606

35561SHAFT, MANUAL VALVE LEVER

main35561-12040iAZT255200309-200606

main35561-21010iAZT250,251200606

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-28100iAZT251200506-200606

main35572-44040iAZT255200606

main35572-48010iAZT250200307-200606

35579PIN, PARKING LOCK PAWL

main35594-21010iAZT250200307-200606

main35594-28010iAZT251200506-200606

35595BRACKET, PARKING LOCK PAWL

main35595-21010iAZT250,251200307-200606

8401

9010506053

main90105-06053

9010506079

main90105-06079

9011908668

main90119-08668

9011908891

main90119-08891

9413000802

main94130-00802

9451200800

main94512-00800

21 parts on this diagram · 2 diagrams in section
