REAR AXLE HOUSING & DIFFERENTIAL

31115CASE, TRANSAXLE

main31105-17020iZZW30200706

main31115-20040iZZW30199910-200403

sub31105-17020

main31115-20041iZZW30200403-200706

sub31105-17020

31115ASEAL, OIL(FOR TRANSAXLE CASE)

main90311-25011iZZW30200201-200509

sub90311-25028

main90311-25016iZZW30199910-200112

main90311-25028iZZW30200509

31115BPLUG, TIGHT(FOR REAR TRANSAXLE CASE)

main90331-08002iZZW30199910-200208

33449AMAGNET, TRANSMISSION

main33449-12020iZZW30199910-200208

33481GEAR, SPEEDOMETER DRIVE (MTM)

main33481-20160iZZW30199910-200208

4102

41221AGEAR, REAR DIFFERENTIAL RING

main41221-12480iZZW30200706

main41221-20350iZZW30199910-200706

sub41221-12480

41222ABOLT (FOR REAR DIFFERENTIAL RING GEAR SET)

main90105-11040iZZW30199910-200208

41301CASE SUB-ASSY, REAR DIFFERENTIAL

main41301-20230iZZW30199910-200208

main41301-32061iZZW30199910-200208

41301ABEARING(FOR REAR DIFFERENTIAL CASE)

main90366-40094iZZW30199910-200208

main90366-40097iZZW30199910-200208

sub90366-40129

41301FSHIM(FOR REAR DIFFERENTIAL CASE)

main90560-41003iZZW30199910-200208

41331GEAR, REAR DIFFERENTIAL SIDE

main41331-32010iZZW30199910-200208

41334CWASHER, PLATE (FOR REAR DIFFERENTIAL SIDE GEAR SHAFT)

main90564-41014iZZW30199910-200208

main90564-41015iZZW30199910-200208

main90564-41016iZZW30199910-200208

main90564-41017iZZW30199910-200208

main90564-41018iZZW30199910-200208

main90564-41019iZZW30199910-200208

main90564-41020iZZW30199910-200208

main90564-41021iZZW30199910-200208

main90564-41022iZZW30199910-200208

main90564-41023iZZW30199910-200208

main90564-41024iZZW30199910-200208

main90564-41025iZZW30199910-200208

main90564-41026iZZW30199910-200208

main90564-41027iZZW30199910-200208

main90564-41028iZZW30199910-200208

main90564-41029iZZW30199910-200208

main90564-41030iZZW30199910-200208

main90564-41031iZZW30199910-200208

main90564-41032iZZW30199910-200208

41341PINION, REAR DIFFERENTIAL

main41341-30011iZZW30199910-200208

41342SHAFT, REAR DIFFERENTIAL PINION

main41342-32020iZZW30199910-200208

sub41342-52060

41342BPIN, STRAIGHT (FOR REAR DIFFERENTIAL PINION SHAFT)

main90250-06058iZZW30199910-200208

41351WASHER, REAR DIFFERENTIAL PINION THRUST

main41351-32010iZZW30199910-200208

41361WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1

main41361-22020iZZW30199910-200208

main41361-22030iZZW30199910-200208

main41361-22040iZZW30199910-200208

main41361-22140iZZW30199910-200208

main41361-22150iZZW30199910-200208

main41361-22160iZZW30199910-200208

18 parts on this diagram · 1 diagram in section
