REAR OIL PUMP & GOVERNOR (ATM)

0001 1 0002 1

35145AADAPTER, GOVERNOR PRESSURE

main35145-32010iAW10..4FC198406-198411

sub35145-32011

main35145-32011iAW10..4FC198411-198608

35145BSPRING, TORSION(FOR GOVERNOR PRESSURE ADAPTER)

main90508-18034iAW10..4FC198406-198608

35149COVER, GOVERNOR

main35149-12010iAW10..4FC198406-198608

main35149-20010iAW10..4FC198608-198912

35149ARING, O (FOR GOVERNOR COVER)

main90301-67001iAW10..4FC198608-198912

main90301-73001iAW10..4FC198406-198608

35157AADAPTER, GOVERNOR BODY

main35157-12010iAW10..4FC198406-198608

main35157-20031iAW10..4FC198608-198912

35185ACOVER, SPEED SENSOR

main35185-12010iAW11..4FC198608-198912

main35185-17010iAW11..4FC198406-198608

35185BRING, O (FOR SPEED SENSOR COVER)

main90301-68001iAW11..4FC198608-198912

main90301-73001iAW11..4FC198406-198608

35186BRACKET, SPEED SENSOR COVER

main35186-12010iAW11..4FC198608-198912

main35186-17010iAW11..4FC198406-198608

35187PLATE, SPEED SENSOR LOCK

main35187-12010iAW11..4FC198608-198912

main35187-17010iAW11..4FC198406-198608

35188ABRACKET, GOVERNOR COVER

main35188-12010iAW10..4FC198406-198608

main35188-20010iAW10..4FC198608-198912

35189WASHER, GOVERNOR THRUST, NO.1

main35189-12010iAW11..4FC198608-198912

main35189-32010iAW10..4FC198406-198803

sub35189-32011

main35189-32011iAW10..4FC198803-198912

35480FBODY ASSY, GOVERNOR

main35480-20021iAW10..4FC198608-198912

main35480-32010iAW10..4FC198406-198608

sub35480-32011

35480GWASHER, PLATE (FOR GOVERNOR BODY)

main90201-25003iAW10..4FC198406-198608

35779GEAR, GOVERNOR DRIVE

main35779-32010iAW10..4FC198406-198608

9161160610

main91611-60610

9165140816

main91651-40816

16 parts on this diagram · 2 diagrams in section
