REAR OIL PUMP & GOVERNOR (ATM)

0001 1A131L,A132L 0002 1A240L,A241L,A241H 0003 1A240E

35145AADAPTER, GOVERNOR PRESSURE

main35145-32011iAE91,EE9#..3FC198705-199108

35145BSPRING, TORSION(FOR GOVERNOR PRESSURE ADAPTER)

main90508-18034iAE91,EE9#..3FC198705-199108

35149COVER, GOVERNOR

main35149-12010iAE91,EE9#..3FC198705-199108

main35149-20010iAE91,95,CE90,96..4FC198705-199108

35149ARING, O (FOR GOVERNOR COVER)

main90301-67001iAE95,CE96..(V,WG)..4FC198705-198908

main90301-68001iAE91,95,CE90..(4D,5D)..4FC198905-199108

main90301-73001iAE91,EE9#..3FC198705-199108

35157AADAPTER, GOVERNOR BODY

main35157-12010iAE91,EE9#..3FC198705-199108

main35157-20031iAE91,95,CE90,96..4FC198705-199108

35188ABRACKET, GOVERNOR COVER

main35188-12010iAE91,EE9#..3FC198705-199108

main35188-20010iAE91,95,CE9#..4FC198705-199108

35189WASHER, GOVERNOR THRUST, NO.1

main35189-32010iAE91,95,CE90,EE90..ATM198705-198803

sub35189-32011

main35189-32011iAE91,95,CE90,96,EE9#..ATM198803-199108

35480FBODY ASSY, GOVERNOR

main35480-12030iAE91,95..4FC198705-199106

main35480-12040iAE91,EE9#..3FC198705-199108

sub35480-16070

main35480-20041iCE90,96..4FC198705-199108

35480GWASHER, PLATE (FOR GOVERNOR BODY)

main90201-25003iAE91,EE9#..3FC198705-199108

35779GEAR, GOVERNOR DRIVE

main35779-32010iAE91,EE9#..3FC198705-199108

9165140816

main91651-40816

11 parts on this diagram · 3 diagrams in section
