CAUTION PLATE & NAME PLATE (ENGINE)

11289PLATE, SPARK PLUG CAUTION

main11289-62020i4EFE,5EFE..EL5#199712

11294PLATE, ENGINE CAUTION, NO.2

main11294-55010i1NT..NL50199409-199710

main11294-55020i1NT..NL50199710

11296PLATE, TIMING BELT CAUTION

main17791-15010i4EFE,5EFE..EL5#199409

main17791-55010i1NT..NL50199409

11296ALABEL, ENGINE SERVICE INFORMATION

main11296-11280i4EFE,5EFE..EL5#199409-199505

main11296-11310i4EFE,5EFE..EL5#199505-199608

main11296-11330i4EFE..EL51199608-199712

main11296-11360i5EFE..EL53,55199712

main11296-11380i4EFE..EL51199712

15369PLATE, ENGINE OIL CAUTION

main15369-54010i1NT..NL50199409-199512

16793PLATE, FAN CAUTION

main16793-46010i4EFE,5EFE..EL5#199701-199702

main16793-74010i1NT..NL50199701-199702

17791LABEL, MAINTENANCE INFORMATION

main11296-55010i1NT..NL50199409

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

8 parts on this diagram · 1 diagram in section
