FRONT BUMPER & BUMPER STAY

0001 1 0002 1 0003 1 0004 1 0005 1

52119ACOVER, FRONT BUMPER

main52119-97201-02iM100,110199809-200112

MAPLE RED M.M.,R27

sub52119-97201

main52119-97201-03iM100,110199809-200112

WARM SILVER M.M.,S20

sub52119-97201

main52119-97201-04iM100,110199809-200112

ROYAL BLUE M.M.,B37

sub52119-97201

main52119-97201-08iM100,110199809-200112

WHITE,W09

sub52119-97201

main52119-97201-09iM100,110199809-200112

MUSTARD YELLOW,Y06

sub52119-97201

main52119-97201-13iM100,110199809-200005

GRAYISH SEPIA ME.,S21

sub52119-97201

main52119-97201-18iM100,110199903-200112

PEARL WHITE,W16

sub52119-97201

main52119-97201-27iM100,110200005-200112

APPLE GREEN M.,G36

sub52119-97201

main52119-97201-37iM100,110200012-200112

BRITISH GREEN MC.,G37

sub52119-97201

main52119-97202-02iM101,111200005-200112

MAPLE RED M.M.,R27

sub52119-97202

main52119-97202-02iM100,110..X199809-199904

sub52119-97202

main52119-97202-03iM100,110..X199809-199904

sub52119-97202

main52119-97202-03iM101,111200005-200112

WARM SILVER M.M.,S20

sub52119-97202

main52119-97202-04iM101,111200005-200112

ROYAL BLUE M.M.,B37

sub52119-97202

main52119-97202-04iM100,110..X199809-199904

sub52119-97202

main52119-97202-08iM100,110..X199809-199904

sub52119-97202

main52119-97202-08iM101,111200005-200112

WHITE,W09

sub52119-97202

main52119-97202-09iM101,111200005-200112

MUSTARD YELLOW,Y06

sub52119-97202

main52119-97202-09iM100,110..X199809-199904

sub52119-97202

main52119-97202-13iM100,110..X199809-199904

sub52119-97202

main52119-97202-17iM101,111200005-200112

APPLE GREEN M.,G36

sub52119-97202

main52119-97202-18iM101,111200005-200112

PEARL WHITE,W16

sub52119-97202

main52119-97202-27iM101,111200012-200112

BRITISH GREEN MC.,G37

sub52119-97202

main52119-97219-02iM100,110199904-200005

sub52119-97219

main52119-97219-03iM100,110199904-200005

sub52119-97219

main52119-97219-04iM100,110199904-200005

sub52119-97219

main52119-97219-08iM100,110199904-200005

sub52119-97219

main52119-97219-09iM100,110199904-200005

sub52119-97219

main52119-97219-13iM100,110199904-200005

sub52119-97219

main52119-97219-18iM100,110199903-200005

sub52119-97219

main52119-97401-02iM101,111200005-200112

sub52119-97401

main52119-97401-04iM101,111200005-200112

sub52119-97401

main52119-97401-07iM101,111200005-200112

sub52119-97401

main52119-97401-08iM101,111200005-200112

sub52119-97401

main52119-97401-09iM101,111200005-200112

sub52119-97401

main52119-97401-13iM101,111200005-200112

sub52119-97401

main52119-97401-18iM101,111200005-200112

sub52119-97401

main52119-97409-02iM101,111..VS200112

RED,R29

sub52119-97409

main52119-97409-03iM101,111..VS200112-200303

COOL SILVER M.,S25

sub52119-97409

main52119-97409-04iM101,111..VS200112-200303

ROYAL BLUE M.M.,B37

sub52119-97409

main52119-97409-08iM101,111..VS200112

WHITE,W09

sub52119-97409

main52119-97409-18iM101,111..VS200112

PEARL WHITE,W16

sub52119-97409

main52119-97409-23iM101,111..VS200303

SILVER ME.,S28

sub52119-97409

main52119-97409-24iM101,111..VS200303

LAVENDER ME. OP.,P10

sub52119-97409

main52119-97411-02iM10#,11#..V200112-200303

RED,R29

sub52119-97411

main52119-97411-04iM10#,11#..V200112-200303

ROYAL BLUE M.M.,B37

sub52119-97411

main52119-97411-05iM100,110..V;M101,111..V,X200112-200303

LIGHT ROSE ME.,T16

sub52119-97411

main52119-97411-07iM100,110..V200205

sub52119-97411

main52119-97411-07iM10#,11#..X200112-200303

BRITISH GREEN MC.,G37

sub52119-97411

main52119-97411-08iM10#,11#..V,X200112-200303

WHITE,W09

sub52119-97411

main52119-97411-13iM10#,11#..V,X200112-200303

WARM SILVER M.M.,S26

sub52119-97411

main52119-97411-14iM100,110..V;M101,111..V,X200112-200303

LIGHT BLUE M.M.,B52

sub52119-97411

main52119-97411-15iM100,110..V;M101,111..V,X200303

CHAMPAGNE ME. OP.,T17

sub52119-97411

main52119-97411-18iM100,110..V;M101,111..V,X200112-200303

PEARL WHITE,W16

sub52119-97411

main52119-97411-23iM100,110..V;M101,111..V,X200303

SILVER ME.,S28

sub52119-97411

main52119-97411-24iM100,110..V200303

LAVENDER ME. OP.,P10

sub52119-97411

52711MOULDING, FRONT BUMPER

main52711-97201iM10#,11#199809-200112

main52711-97202iM100,110199809-200112

52712MOULDING, FRONT BUMPER SIDE, RH

main52712-97201iM10#,11#199809-200112

main52712-97203iM100,110199809-200112

main52712-97401iM10#,11#200112

52712BCLIP, FRONT BUMPER MOULDING

main90044-67430iM10#,11#199809-200112

52712CCLIP, FRONT BUMPER MOULDING, NO.2

main90044-68307iM10#,11#199809-200112

52713AMOULDING, FRONT BUMPER SIDE, LH

main52713-97201iM10#,11#199809-200112

main52713-97203iM100,110199809-200112

main52713-97401iM10#,11#200112

52721MOULDING, FRONT BUMPER EXTENSION, RH

main52721-97201iM10#,11#199809-200112

main52721-97401iM101,111200005-200112

52721BCLIP, FRONT BUMPER EXTENSION MOULDING, NO.2

main90044-68196iM10#,11#199809-200112

52722MOULDING, FRONT BUMPER EXTENSION, LH

main52722-97201iM10#,11#199809-200112

main52722-97401iM101,111200005-200112

53112DGRILLE, RADIATOR, LOWER RH

main53112-97201iM100,110199809-200005

main53112-97401iM101,111200005-200112

main53112-97402iM10#,11#200005-200112

53113DGRILLE, RADIATOR, LOWER LH

main53113-97201iM100,110199809-200005

main53113-97401iM101,111200005-200112

main53113-97402iM10#,11#200005-200112

9004109219

main90041-09219

9004119564

main90041-19564

9004159306

main90041-59306

9004179134

main90041-79134

9004183058

main90041-83058

9004189026

main90041-89026

9004189045

main90041-89045

9354056016

main93540-56016

19 parts on this diagram · 5 diagrams in section
