CAUTION PLATE & NAME PLATE (ENGINE)

0001 1 0002 1

11278PLATE, ENGINE EMISSION IDENTIFICATION

main11278-54020i3B,1HZ..BB40,HZB50..ARL199301-200211

main11278-58010i15BFT..BB50..EX199705-199907

SINGAPORE SPEC

main11278-58020i15BFTE..BB50..EX199907-200608

main11278-64010i1HZ..HZB50..SCO199301-199705

SINGAPORE SPEC

11283PLATE, TURBOCHARGER CAUTION

main11294-64050i1HZT..HZB50199301-199508

11284PLATE, ENGINE BOLT INFORMATION

main11284-17010i1HZ#..HZB50199301-199501

sub11297-17010

main11284-17030i1HZ..HZB50..LHD..GEN..5F199301-199502

CHINA SPEC

sub11297-17020

main11284-56040i14B,15BFT,3B..BB4#,5#199301-199905

main11284-58010i14B..BB42..LHD..HRF199301-199905

CHINA SPEC

main11284-58010i14B..BB42..LHD..HRF..26S199705-199905

CHINA OR YOJO SPEC

main11297-17010i1HZ#..HZB50199501-199907

main11297-17020i1HZ..HZB50..LHD..GEN..5F199502-200008

CHINA SPEC

11291PLATE, ENGINE NAME

main11291-17020i1HZT..HZB50199301-199605

main11291-58030i15BFT..BB50..EUR199605-200105

main11291-58040i15BFTE..BB50..IV200105-200608

11293PLATE, ENGINE CAUTION & ENGINE NAME

main11293-56080i15BFTE..BB50,59;14B..BB42..WC..GCC;14B..BB42..SRF..GEN;14B..BB42..HRF..26S..WC;14B..BB42..LHD..HRF..WOC;15BFT..BB50..STD..GEN..CBU..5F199301-201501

11293BLABEL, TUNE-UP SPECIFICATION INFORMATION

main11293-56090i14B..BB42..LHD..HRF..WC199301-200012

CHINA SPEC

main11293-56090i14B..BB42..LHD..HRF..26S..WC200012-200108

YOJO SPEC

main11293-56090i15BFT..BB50..CHI200008-200211

main11293-56090i14B..BB42..22S199705-199907

CHINA OR YOJO SPEC

11296ALABEL, ENGINE SERVICE INFORMATION

main11296-17020i1HZT..HZB50199301-199605

sub11296-17110

main11296-17030i1HZ..HZB50199301-199604

sub11296-17120

main11296-17040i1HZ..HZB50..LHD..GEN..5F199301-199705

CHINA SPEC

main11296-17120i1HZ..HZB50..LHD..EX;1HZ..HZB50..LHD..WOC;1HZ..HZB50..HRF..30S..WC;1HZ..HZB50..LHD..SRF..WC199604-201501

main11296-17160i1HZ..HZB50..LHD..HRF..WC..GEN199705-200008

CHINA SPEC

main11296-48050i1BZFPE..BZB40,50200108-200408

main11296-48051i1BZFPE..BZB40,50200408-201501

main11296-75050i3RZF..RZB40,50..GEN199309-199610

CHINA SPEC

main11296-75110i3RZF..RZB40,50..HRF..GEN199610-199907

CHINA SPEC

11298PLATE, EMISSION CONTROL INFORMATION

main11298-17011i1HZ..HZB50..ARL199301-199505

main11298-17012i1HZ..HZB50..ARL199505-199907

main11298-17020i1HZ..HZB50..ARL199907-200201

main11298-58010i14B..BB42..LHD..HRF..26S199305-199409

TAIWAN SPEC

main11298-58011i14B..BB42..LHD..HRF..26S199409-199505

TAIWAN SPEC

main11298-58012i14B..BB42..LHD..HRF..26S199505-199602

TAIWAN SPEC

main11298-58013i14B..BB42..LHD..HRF..26S199602-199612

TAIWAN SPEC

main11298-58014i14B..BB42..LHD..HRF..26S199612-199705

TAIWAN SPEC

main11298-58020i15BFT..BB58199705-199710

main11298-58021i15BFT..BB58199710-199810

main11298-58022i15BFT..BB58199810-199907

11298ALABEL, EMISSION CONTROL INFORMATION

main11298-58060i15BFT..BB50..WC201108-201501

main11298-78010iN04C..XZB50..30S..WC201501

16701GLABEL, CAUTION

main16793-28020i1HZ..HZB50200902-201501

TYPE B:REFER ILLUST.

sub16793-36040

main16793-31070i1HZ..HZB50..WOC201602

TYPE C:REFER ILLUST.

main88723-12100i1HZ#..HZB50..EUR,GCC,GEN,SCO199301-199907

TYPE A:REFER ILLUST.

main88723-20081i1HZ..HZB50..RHD..SRF;1HZ..HZB50..RHD..WOC..GEN;1HZ..HZB50..RHD..(20S,22S)..GEN199907-200902

TYPE A:REFER ILLUST.

sub16793-31070

17700CPLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)

main17791-64020i15BFT,1HZT..BB50,HZB50..EUR199301-199907

main90917-07108i14B,3B..BB40,42199301-199907

CASE SIDE

main90917-07109i15BFT,1HZ,3RZFE..BB50,HZB50,RZB40,50..ARL,CHI199907-201501

main90917-07109i1HZ,3RZF..HZB50,RZB40,50199301-199907

ELEMENT SIDE

17791LABEL, MAINTENANCE INFORMATION

main17791-55010i1HZ#..HZB50199301-199705

17792PLATE, ENGINE VACUUM HOSE INFORMATION

main17792-75070i3RZF..RZB40,50199309-199907

main17792-75250i3RZF..RZB40,50..HRF..GEN199705-199907

CHINA SPEC

23923PLATE, FUEL SEDIMENTER CAUTION

main23923-64021i14B,3B,1HZ..BB4#,HZB50199301-199505

1356410010LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010

15 parts on this diagram · 2 diagrams in section
