BACK DOOR LOCK & HINGE
6451
65706ASTAY SUB-ASSY, TAIL GATE, RH
main65706-60032iURJ202..VX..GEN;VDJ200..RHD..LUB;VDJ200..GXR..GCC;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..(GXR,VXR)..GCC201908-202104
65707ASTAY SUB-ASSY, TAIL GATE, LH
main65706-60032iURJ202..ARL;GRJ200..5F..LUB;URJ202..VX..GCC;URJ202..VXR..GEN;VDJ200..LHD..5F..GEN..LUB;VDJ200..(GX,VX,VXR)..GCC..LUB201908-202103
66110HHINGE ASSY, TAIL GATE, RH
main66110-60031iGRJ200..5F..LUB;URJ202..VX..GCC;URJ202..VXR..GEN;URJ202..(GXR,VX)..ARL;VDJ200..LHD..5F..GEN..LUB;VDJ200..(05S,08S)..(GX,VX,VXR)..GCC..LUB201512-202103
66120GHINGE ASSY, TAIL GATE, LH
main66110-60031iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201512-202104
TAILGATE DOOR EASY CLOSER-WITH
main66120-60021iURJ200;URJ202..VX..GEN;URJ202..VXR..(ARL,GCC);VDJ200..(VX,VXR)..(ARL,GEN)201512-202104
TAILGATE DOOR EASY CLOSER-WITH
67281FSTOPPER, BACK DOOR, LOWER
67293ACUSHION, BACK DOOR STOPPER
main67293-60050×2iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201508-202104
68810DHINGE ASSY, BACK DOOR, RH
sub68810-28041
PAD T=1.0
main68810-60021iGRJ200..5F..LUB;URJ202..VX..GCC;URJ202..VXR..GEN;URJ202..(GXR,VX)..ARL;VDJ200..LHD..5F..GEN..LUB;VDJ200..(05S,08S)..(GX,VX,VXR)..GCC..LUB201512-202103
PAD T=1.0
PAD T=1.5
main68810-60031iGRJ200..5F..LUB;URJ202..VX..GCC;URJ202..VXR..GEN;URJ202..(GXR,VX)..ARL;VDJ200..LHD..5F..GEN..LUB;VDJ200..(05S,08S)..(GX,VX,VXR)..GCC..LUB201512-202103
PAD T=1.5
PAD T=2.0
main68810-60041iGRJ200..5F..LUB;URJ202..VX..GCC;URJ202..VXR..GEN;URJ202..(GXR,VX)..ARL;VDJ200..LHD..5F..GEN..LUB;VDJ200..(05S,08S)..(GX,VX,VXR)..GCC..LUB201512-202103
PAD T=2.0
68820CHINGE ASSY, BACK DOOR, LH
sub68810-28041
PAD T=1.0
main68810-60021iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201512-202104
PAD T=1.0
PAD T=1.5
main68810-60031iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201512-202104
PAD T=1.5
PAD T=2.0
main68810-60041iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201512-202104
PAD T=2.0
68846BGUIDE, BACK DOOR TORSION BAR
main68846-60010iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201508-202104
68870BAR ASSY, BACK DOOR LOWER TORSION
main68870-60021iURJ202..VX..GEN;VDJ200..RHD..LUB;VDJ200..GXR..GCC;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..(GXR,VXR)..GCC202001-202104
TAILGATE DOOR EASY CLOSER-WITH
URBAN STYLE/TRD-PACKAGE(20INCH)&TAILGATE DOOR EASY CLOSER-WITH
68950CSTAY ASSY, BACK DOOR, RH
main68950-0WD81iGRJ200..5F..LUB;URJ202..VX..GCC;URJ202..VXR..GEN;URJ202..(GXR,VX)..ARL;VDJ200..LHD..5F..GEN..LUB;VDJ200..(05S,08S)..(GX,VX,VXR)..GCC..LUB201611-202103
SPARE WHEEL CARRIER-BACK DOOR FRAME&REAR SPOILER-WITH&REAR WINDOW WIPER-WITH(INTERMITTENT)
REAR SPOILER-WITH
REAR SPOILER-WITH
main68950-0WD90iVDJ200..RHD..5F..LUB;VDJ200..(GX,GXR)..GCC..LUB;VDJ200..LHD..6FC..GXR..GEN;GRJ200,URJ202..LHD..(GX,GXR)..LUB201608-201702
AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
SPARE WHEEL CARRIER-REAR UNDER FRAME & BACK DOOR FRAME
TAILGATE DOOR EASY CLOSER-WITH
main68950-0WE01iURJ200;URJ202..VX..GEN;URJ202..VXR..(ARL,GCC);VDJ200..(VX,VXR)..(ARL,GEN)201610-202104
TAILGATE DOOR EASY CLOSER-WITH
TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
REAR SPOILER-WITH&TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV +DVD + AM/FM JBL 14SPEAKER
REAR SPOILER-WITH&TAILGATE DOOR EASY CLOSER-WITH
REAR SPOILER-WITH&TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV +DVD + AM/FM JBL 14SPEAKER
REAR SPOILER-WITH&TAILGATE DOOR EASY CLOSER-WITH
main68950-69255iVDJ200..RHD..5F..LUB;VDJ200..LHD..6FC..(GX,GXR);GRJ200,URJ202..LHD..(GX,GXR)..LUB201508-201608
AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
TAILGATE DOOR EASY CLOSER-WITH
TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
68960STAY ASSY, BACK DOOR, LH
main68960-0WD81iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201611-202104
REAR SPOILER-WITH
REAR SPOILER-WITH
REAR SPOILER-WITH
main68960-0WD90iVDJ200..RHD..5F..LUB;VDJ200..(GX,GXR)..GCC..LUB;VDJ200..LHD..6FC..GXR..GEN;GRJ200,URJ202..LHD..(GX,GXR)..LUB201608-201702
AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
main68960-0WD91iGRJ200..05S..5FC;GRJ200..(08S,09S)..LUB;VDJ200..LHD..6FC..GXR..GEN;VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201703-201908
SPARE WHEEL CARRIER-REAR UNDER FRAME & BACK DOOR FRAME&REAR WINDOW WIPER-WITH(INTERMITTENT & WASHER CONTROL)
TAILGATE DOOR EASY CLOSER-WITH
TAILGATE DOOR EASY CLOSER-WITH
TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
REAR SPOILER-WITH&TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV +DVD + AM/FM JBL 14SPEAKER
REAR SPOILER-WITH&TAILGATE DOOR EASY CLOSER-WITH
REAR SPOILER-WITH&TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV +DVD + AM/FM JBL 14SPEAKER
REAR SPOILER-WITH&TAILGATE DOOR EASY CLOSER-WITH
main68960-69205iVDJ200..RHD..5F..LUB;VDJ200..LHD..6FC..(GX,GXR);GRJ200,URJ202..LHD..(GX,GXR)..LUB201508-201608
AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
TAILGATE DOOR EASY CLOSER-WITH
TAILGATE DOOR EASY CLOSER-WITH&AUDIO(FOR OVERSEAS MARKET)-EMV & DVD & JBL & 14SPEAKER
68961BOLT, BACK DOOR STAY
main68961-12050×2iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201508-202104
69195GRIP, BACK DOOR
main69195-60011iGRJ200..5F..LUB;URJ202..VX..GCC;URJ202..VXR..GEN;URJ202..(GXR,VX)..ARL;VDJ200..LHD..5F..GEN..LUB;VDJ200..(05S,08S)..(GX,VX,VXR)..GCC..LUB201508-202103
69291HANDLE ASSY, BACK DOOR INSIDE
main69291-60030iURJ202..VX..GCC;VDJ200..09S..SOB;URJ202..(GXR,VX)..ARL;VDJ200..(VX,VXR)..GCC;VDJ200..05S..(ARL,GCC);VDJ200..LHD..5F..GEN..LUB;GRJ200..(05S,08S)..5F..GCC;GRJ200,URJ2201508-202103
69299GROMMET, BACK DOOR HANDLE
main69299-60010iGRJ200..09S..SOB;VDJ200..ARL..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);VDJ200..RHD..(05S,08S)..GEN;GRJ200,URJ202..(05S,08S)..(GX,VX)..GEN201508-202104
69321COVER, BACK DOOR LOCK
main69321-60030iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201508-202104
69350PLOCK ASSY, BACK DOOR, W/COURTESY LAMP SWITCH
sub69350-60141
main69350-60200iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201508-202104
TAILGATE DOOR EASY CLOSER-WITH
TAILGATE DOOR EASY CLOSER-WITH
69380ALOCK ASSY, TAIL GATE, LOWER RH
main69380-60061iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201512-202104
TAILGATE DOOR EASY CLOSER-WITH
OFF LOAD PACKAGE&TAILGATE DOOR EASY CLOSER-WITH
69390ALOCK ASSY, TAIL GATE, LOWER LH
main69390-60051iGRJ200..5F..LUB;URJ202..VX..GCC;URJ202..VXR..GEN;URJ202..(GXR,VX)..ARL;VDJ200..LHD..5F..GEN..LUB;VDJ200..(05S,08S)..(GX,VX,VXR)..GCC..LUB201512-202103
TAILGATE DOOR EASY CLOSER-WITH
main69390-60061iURJ200;URJ202..VX..GEN;URJ202..VXR..(ARL,GCC);VDJ200..(VX,VXR)..(ARL,GEN)201512-202104
TAILGATE DOOR EASY CLOSER-WITH
69431ASTRIKER, REAR SWING GATE LOCK
main69431-60010iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201508-202104
69450CSTRIKER ASSY, BACK DOOR LOCK, RH
69460BSTRIKER ASSY, BACK DOOR LOCK, LH
main69460-60040iURJ202..VX..GEN;VDJ200..RHD..LUB;GRJ200,URJ200..ATM;VDJ200..LHD..6FC..GEN;URJ202..VXR..(ARL,GCC);URJ202,VDJ200..(08S,09S)..(GX,GXR)..GCC..LUB201508-202104
69478CUSHION, BACK DOOR LOWER STOPPER
69690CONTROL ASSY, BACK DOOR REMOTE
OFF LOAD PACKAGE&TAILGATE DOOR EASY CLOSER-WITH
6929660010SCREW, DOOR INSIDE HANDLE
main69296-60010
9010508187
main90105-08187
9011906779
main90119-06779
9011906904
main90119-06904
9011906911
main90119-06911
9011908061
main90119-08061
9011908892
main90119-08892
9011908B78
main90119-08B78
9014860073
main90148-60073
9014880040
main90148-80040
9015960072
main90159-60072
9017908096
main90179-08096
9095001690
main90950-01690
91673A0622
main91673-A0622
40 parts on this diagram · 4 diagrams in section
