TRANSMISSION GEAR (MTM)
33311SHAFT, INPUT
N=21,FOR 4-SPEED TRANSMISSION
N=22,FOR 4-SPEED TRANSMISSION
N=22,FOR 4-SPEED TRANSMISSION
N=22
N=22,FOR 4-SPEED TRANSMISSION
N=17,FOR 3-SPEED TRANSMISSION
N=17
33311ABEARING (FOR INPUT SHAFT FRONT)
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33311BRING, SHAFT SNAP (FOR FRONT BEARING)
T=3.31-3.42,T=3.31-3.42,FOR 4-SPEED T/M
T=3.31-3.42,T=3.31-3.42
T=3.20-3.31,T=3.20-3.31,FOR 4-SPEED T/M
T=3.20-3.31,T=3.20-3.31
33311CRING, HOLE SNAP (FOR NEEDLE ROLLER)
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33311DBEARING, INPUT SHAFT
FOR 4-SPEED TRANSMISSION
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33321SHAFT, OUTPUT
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33321ABEARING (FOR OUTPUT SHAFT REAR)
FOR 4-SPEED TRANSMISSION
sub90363-35021
FOR 4-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33321DRING, SHAFT SNAP (FOR CLUTCH HUB SET)
T=2.40-2.50,FOR 4-SPEED T/M
T=2.50-2.60,FOR 4-SPEED T/M
T=2.60-2.70,FOR 4-SPEED T/M
T=2.35-2.40,MARK 12,T=2.35-2.40,FOR 3-SPEED T/M
T=2.35-2.40,MARK 12,T=2.35-2.40
T=2.25,MARK 5,T=2.25-2.30,FOR 3-SPEED T/M
T=2.25,MARK 5,T=2.25-2.30
T=2.40-2.45,T=2.40-2.45,FOR 4-SPEED T/M
T=2.40-2.45,T=2.40-2.45
T=2.45-2.50,T=2.45-2.50
T=2.45-2.50,T=2.45-2.50,FOR 4-SPEED T/M
T=2.50-2.55,T=2.50-2.55
T=2.50-2.55,T=2.50-2.55,FOR 4-SPEED T/M
T=2.55-2.60,T=2.55-2.60
T=2.55-2.60,T=2.55-2.60,FOR 4-SPEED T/M
T=2.60-2.65,T=2.60-2.65,FOR 4-SPEED T/M
T=2.60-2.65,T=2.60-2.65
T=2.65-2.70,T=2.65-2.70,FOR 4-SPEED T/M
T=2.65-2.70,T=2.65-2.70
33321GNUT (FOR MANUAL TRANSMISSION OUTPUT SHAFT REAR SET)
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33331GEAR, REVERSE
N=25
33332GEAR, 2ND
N=23,3-SPEED TRANSMISSION
N=23
N=23,FOR 3-SPEED TRANSMISSION
N=33,FOR 4-SPEED TRANSMISSION
N=33,FOR 4-SPEED TRANSMISSION
N=33
33362HUB, TRANSMISSION CLUTCH, NO.2
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33366KEY, SYNCHROMESH SHIFTING, NO.2
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33368RING, SYNCHRONIZER, NO.2
FOR 4-SPEED TRANSMISSION
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33391SPRING, SYNCHROMESH SHIFTING KEY, NO.2
FOR 4-SPEED TRANSMISSION
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33402GEAR SUB-ASSY, REVERSE IDLER
N=28,FOR 4-SPEED TRANSMISSION
N=28,FOR 4-SPEED TRANSMISSION
N=28
N=13,FOR 3-SPEED TRANSMISSION
N=13
33402BROLLER (FOR REVERSE IDLER)
33402CWASHER, PLATE (FOR REVERSE IDLER)
33411COUNTERSHAFT
N=21,14,14,FOR 4-SPEED T/M
FOR 3-SPEED TRANSMISSION
33411ABEARING OR ROLLER(FOR COUNTER GEAR FRONT)
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33411BSPACER(FOR COUNTER GEAR BEARING)
FOR 4-SPEED TRANSMISSION
FOR 3-SPEED TRANSMISSION
33411CKEY, WOODRUFF(FOR COUNTER GEAR SHAFT)
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33411HBEARING OR ROLLER(FOR COUNTER GEAR REAR)
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
33421GEAR, COUNTER
N=37,31,21,14,14 FOR 4-T/M
N=37,31,21,14,14
N=38,FOR 4-SPEED TRANSMISSION
N=30,24,16,12,FOR 3-SPEED T/M
N=30,24,16,12
N=37,FOR 4-SPEED TRANSMISSION
33421ATUBE(FOR COUNTER GEAR)
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSHISSION
33435WASHER, COUNTER GEAR CASE SIDE THRUST
33441WASHER, COUNTER GEAR SIDE THRUST, NO.1
T=1.45-1.50
T=1.50-1.55
T=1.55-1.60
33451AKEY, WOODRUFF (FOR REVERSE IDLER GEAR SHAFT)
FOR 3-SPEED TRANSMISSION
FOR 4-SPEED TRANSMISSION
sub90280-03015
33453SPACER, REVERSE IDLER GEAR SHAFT
36253LOCK, INPUT SHAFT NUT
33 parts on this diagram · 3 diagrams in section
