THROTTLE LINK & VALVE LEVER (ATM)

0001 1A750F 0002 1AC60F

3312

35501ROD SUB-ASSY, PARKING LOCK

main35501-60030iKDJ150..5FC201708-202007

main35501-71020iGDJ150,GRJ150,TRJ15#..6FC201708-202312

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-26010iGDJ150,GRJ150,TRJ15#..6FC201708-202312

main35505-60070iKDJ150..5FC201708-202007

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iGDJ150,GRJ150,KDJ150,TRJ15#..ATM201708-202312

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iGDJ150,GRJ150,KDJ150,TRJ15#..ATM201708-202312

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20025iGDJ150,GRJ150,KDJ150,TRJ15#..ATM201708-202312

35556SHAFT, PARKING LOCK PAWL

main35556-60020iGDJ150,GRJ150,KDJ150,TRJ15#..ATM201708-202312

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iGDJ150,GRJ150,KDJ150,TRJ15#..ATM201708-202312

35557PAWL, PARKING LOCK

main35557-60040iKDJ150..5FC201708-202007

main35557-71010iGDJ150,GRJ150,TRJ15#..6FC201708-202312

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90949-03123iGDJ150,GRJ150,KDJ150,TRJ15#..ATM201708-202312

35561SHAFT, MANUAL VALVE LEVER

main35561-60030iGDJ150,GRJ150,KDJ150,TRJ15#..ATM201708-202312

35573LEVER, TRANSMISSION CONTROL SHAFT, LH

main35573-60020iKDJ150..5FC201708-202007

main35573-71010iGDJ150,GRJ150,TRJ15#..6FC201708-202312

35595BRACKET, PARKING LOCK PAWL

main35595-60030iKDJ150..5FC201708-202007

main35595-71010iGDJ150,GRJ150,TRJ15#..6FC201708-202312

91611B0614

main91611-B0614

9413000802

main94130-00802

9451200800

main94512-00800

16 parts on this diagram · 2 diagrams in section
