REAR DISC BRAKE CALIPER & DUST COVER

0001 1 0002 1 0004 1 0006 1

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-60030iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥1,200199208-200701

04492PAD KIT, DISC BRAKE, REAR

main04492-60010iFZJ70,75,HZJ7#..ARL¥10,000199208-199505

sub04466-60010¥9,400

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥160199208-200701

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-12030iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥400199208-200701

47713APLUG, HOLE(FOR REAR DISC BRAKE CYLINDER)

main90950-01301iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥80199208-200701

47715CPIN, CYLINDER SLIDE(FOR REAR DISC BRAKE)

main47715-22010iFZJ70,75,78,79,HZJ70,75,78,79..ARL¥570199208-200001

main47715-43010iHZJ78..LX;HZJ79..ARL..CBU¥550200001-200701

47716APLATE, PAD SUPPORT, NO.1(FOR REAR DISC BRAKE)

main47716-22010iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥190199208-200701

47717APLATE, PAD SUPPORT, NO.2(FOR REAR DISC BRAKE)

main47717-22010iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥190199208-200701

47721CMOUNTING, REAR DISC BRAKE CYLINDER, RH

main47721-60010iFZJ70,75,HZJ7#..ARL¥6,200199208-199210

main47721-60020iHZJ75..LHD..IV;FZJ75,HZJ75..ARL¥4,000199210-200701

47722AMOUNTING, REAR DISC BRAKE CYLINDER, LH

main47722-60010iFZJ70,75,HZJ7#..ARL¥6,200199208-199210

main47722-60020iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥4,000199210-200701

47730BCYLINDER ASSY, REAR DISC BRAKE, RH

main47730-60040iFZJ70,75,HZJ7#..ARL¥41,800199208-199210

sub47730-60070¥41,800

main47730-60070iFZJ70,75,HZJ7#..ARL¥41,800199210-199801

sub47730-60110¥21,500

main47730-60110iHZJ75..LHD..IV;FZJ75,HZJ75..ARL¥21,500199801-200701

47731BPISTON, REAR DISC BRAKE

main47731-60020iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥1,200199208-200701

47744CSHIM, ANTI-SQUEAL, NO.1(FOR REAR DISC BRAKE)

main47744-60010iFZJ70,75,HZJ7#..ARL¥170199208-199908

47750ACYLINDER ASSY, DISC BRAKE, REAR LH

main47750-60040iFZJ70,75,HZJ7#..ARL¥41,800199208-199210

sub47750-60070¥41,800

main47750-60070iFZJ70,75,HZJ7#..ARL¥41,800199210-199801

sub47750-60110¥21,500

main47750-60110iHZJ75..LHD..IV;FZJ75,HZJ75..ARL¥21,500199801-200701

47771APLATE, PAD WEAR INDICATOR(FOR REAR DISC BRAKE)

main47771-22030iFZJ70,75,78,79,HZJ70,75,78,79..ARL¥140199208-200701

47777PROTECTOR, DUST BOOT, RH

main47777-60010iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥490199208-200701

47787APROTECTOR, DUST BOOT, LH

main47777-60010iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥490199208-200701

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90101-12167iFZJ70,75,78,79,HDJ7#,HZJ70,75,78,79..ARL¥110199208-200701

9011006007

main90110-06007¥200

9020112452

main90201-12452¥170

9451100600

main94511-00600¥120

21 parts on this diagram · 4 diagrams in section
