DISC WHEEL & WHEEL CAP
42601AWHEEL, DISC (FOR SPARE)
17.5X5.25, #,TYPE B:REFER ILLUST.
17.5X6.00, #,TYPE B:REFER TO ILLUSTRATION
sub42601-37730
16X5.5K, #,TYPE D:REFER ILLUST.
16X6K, #,TYPE D:REFER ILLUST.
6.00GSX16, #,TYPE F:REFER ILLUST.
42601CNUT, HUB (FOR AXLE)
TYPE A:REFER TO ILLUSTRATION,RH
TYPE A:REFER TO ILLUSTRATION,LH
TYPE B:REFER TO ILLUSTRATION,RH
TYPE B:REFER TO ILLUSTRATION,LH
42601FWHEEL, DISC (FOR FRONT)
17.5X5.25, #,TYPE B:REFER ILLUST.
16X5.5K, #,TYPE D:REFER ILLUST.
16X6K, #,TYPE D:REFER ILLUST.
6.00GSX16, #,TYPE F:REFER ILLUST.
42601RWHEEL, DISC (FOR REAR)
17.5X5.25, #,TYPE B:REFER ILLUST.
16X5.5K, #,TYPE D:REFER ILLUST.
16X6K, #,TYPE D:REFER ILLUST.
6.00GSX16, #,TYPE F:REFER ILLUST.
42611GVALVE (FOR TUBELESS TIRE)
TYPE A:REFER TO ILLUSTRATION
TYPE B:REFER TO ILLUSTRATION
TYPE C:REFER TO ILLUSTRATION
42611JVALVE (FOR TUBELESS TIRE SPARE)
TYPE A:REFER TO ILLUSTRATION
TYPE B:REFER TO ILLUSTRATION
TYPE C:REFER TO ILLUSTRATION
42613ARING, DISC WHEEL SIDE
42652TIRE
7.50R16-12
205/60R17.5
42652ATIRE (FOR SPARE)
7.50R16-12
205/60R17.5
9 parts on this diagram · 4 diagrams in section
