REAR AXLE HOUSING & DIFFERENTIAL
41101CARRIER SUB-ASSY, DIFFERENTIAL, REAR
10.5 INCHES
41110CARRIER ASSY, DIFFERENTIAL, REAR
R=37:6=6.167
R=39:8=4.875
R=41:8=5.125
R=37:6=6.167
R=35:6=5.833
R=41:6=6.833
R=39:7=5.571
R=39:7=5.571
R=37:6=6.167
R=41:6=6.833
41114BOLT, REAR DIFFERENTIAL BEARING CAP
14-1.5PX85.5-25
41201FINAL GEAR KIT, DIFFERENTIAL, REAR
41201CSEAL, OIL (FOR REAR DIFFERENTIAL CARRIER)
sub90311-38134
sub90311-38047
sub90311-48135
sub90311-48019
41201ESHIM (FOR REAR DIFF DRIVE PINION SPACER FRONT ADJUST)
T=0.25,T=0.23-0.27
T=0.43-0.47
T=0.28-0.32
T=0.33-0.37
T=0.38-0.42
T=1.80,T=1.80
T=1.82,T=1.82
T=1.84,T=1.84
T=1.86,T=1.86
T=1.88,T=1.88
T=1.90,T=1.90
T=2.00,T=2.00
T=2.10,T=2.10
T=2.20,T=2.20
T=2.30,T=2.30
T=2.40,T=2.40
T=2.50,T=2.50
T=2.60,T=2.60
T=2.70,T=2.70
T=2.80,T=2.80
T=2.90,T=2.90
T=3.00,T=3.00
T=0.25
T=0.3
T=0.35
T=0.45
T=0.40
41201FSHIM (FOR REAR DIFF DRIVE PINION SPACER REAR ADJUST)
OD=47,T=1.70,T=1.70
OD=47,T=1.73,T=1.73
OD=47,T=1.76,T=1.76
OD=47,T=1.79,T=1.79
OD=47,T=1.82,T=1.82
OD=47,T=1.85,T=1.85
OD=47,T=1.88,T=1.88
OD=47,T=1.91,T=1.91
OD=47,T=1.94,T=1.94
OD=47,T=1.97,T=1.97
OD=47,T=2.00,T=2.00
OD=47,T=2.03,T=2.03
OD=47,T=2.06,T=2.06
OD=47,T=2.09,T=2.09
OD=47,T=2.12,T=2.12
OD=47,T=2.15,T=2.15
OD=47,T=2.18,T=2.18
OD=47,T=2.21,T=2.21
OD=47,T=2.24,MARK 01,T=2.24
OD=47,T=2.27,MARK 02,T=2.27
OD=47,T=2.30,MARK 03,T=2.30
OD=47,T=2.33,MARK 04,T=2.33
T=0.25
T=0.3
T=0.35
T=0.45
T=0.40
T=0.30
T=0.35
T=0.40
T=0.45
T=0.50
T=0.55
T=0.25,T=0.25
T=0.30,T=0.30
T=0.35,T=0.35
T=0.40,T=0.40
T=0.45,T=0.45
41201JWASHER, PLATE (FOR FRONT BEARING FRONT)
sub41214-26010
41204FLANGE SUB-ASSY, REAR DRIVE PINION COMPANION, REAR
sub41204-26012
sub41204-35021
sub41204-36H01
sub41204-36H02
41204AWASHER, PLATE (FOR REAR DRIVE PINION)
41204BNUT (FOR REAR DRIVE PINION)
41222PLATE, REAR DIFFERENTIAL RING GEAR SET BOLT LOCK
41222ABOLT (FOR REAR DIFFERENTIAL RING GEAR SET)
41231SPACER, REAR DIFFERENTIAL DRIVE PINION BEARING
41315NUT, REAR DIFFERENTIAL BEARING ADJUSTING
41316LOCK, REAR DIFFERENTIAL BEARING ADJUSTING NUT
SINGLE TYPE
SINGLE TYPE
SINGLE TYPE
DOUBLE TYPE
DOUBLE TYPE
DOUBLE TYPE
41331GEAR, REAR DIFFERENTIAL SIDE
N=16
41341PINION, REAR DIFFERENTIAL
41342SHAFT, REAR DIFFERENTIAL PINION
41343PIN, REAR DIFFERENTIAL PINION SHAFT
41361WASHER, REAR DIFFERENTIAL SIDE GEAR THRUST, NO.1
T=1.6,T=1.6
T=1.7,T=1.7
T=1.8,T=1.8
9111140814
main91111-40814
9451200800
main94512-00800
9451201000
main94512-01000
9453101200
main94531-01200
31 parts on this diagram · 7 diagrams in section
