CAUTION PLATE

0001 1ENGINE ROOM & EXTERIOR 0002 1INTERIOR

11285ALABEL, COOLANT SYSTEM NOTICE

main11285-0E010i1GDFTV..GUN156..PKN202006-202204

11285FLABEL, COOLANT SYSTEM CAUTION

11289BLABEL, SPARK PLUG NOTICE

main11289-31011i1GRFE..GGN155..EPT,GCC,GEN¥170202006-202203

11295BLABEL, ENGINE SERVICE NOTICE, NO.1

main11295-0E010i1G#,2GDFTV,2TRFE..GGN155,GUN156,165,TGN156,16#..AGTSU¥170202101-202204

11298BLABEL, EMISSION CONTROL INFORMATION

main11298-0E030i1GDFTV..GUN156,166..PH202007-202108

main11298-0E040i2GDFTV..GUN165..PH202007-202108

74515CLABEL, THEFT WARNING INFORMATION

main74515-02080iGUN156,166,TGN166..IND202101-202109

main74515-0K020iTGN156..SA¥480202006-202204

main74515-0K020iGUN156..BZAGT;GUN156..H..LA;GGN155,TGN168..AGTSU;TGN156,166..AGTSU..6FC..(H,S)¥480202006-202110

ANTI-THEFT SYSTEM-WITH(IMMOBILIZER & SECURITY HORN)

main74515-42010iGUN15#,16#,TGN156..RHD..(MA,SA)¥300202009-202110

74559BLABEL, FUEL INFORMATION

main74559-02040iTGN168202011-202110

main74559-0K020iGUN15#,16#,LAN155..SA202009-202109

main74559-20140iGGN155,TGN156,166..AGTSU¥50202006-202204

main74559-89101iGUN15#,16#..ARL,GCC,GEN,IDN,IND,MA,PH,VN¥100202006-202204

main74559-YE010iGUN15#,16#..TH202006-202108

74567APLATE, E.C.E APPROVED NUMBER

main74567-25041iGUN156..ARL¥110202006-202108

74751LABEL, TIRE PRESSURE INFORMATION

main42661-0KP40iTGN166..PKN202006-202203

main42661-0KP50iGGN155,GUN165..H..(GEN,VN);GGN155,GUN155,165,TGN156,166..(IDNSU,VNSUV)..(L,S)202007-202204

main42661-0KP60iGUN15#,16#,LAN155,TGN156..SA202009-202109

main42661-0KP70iGUN156..H..LA;GUN156..AGTSU..(L,S);GGN155,GUN165,TGN156,16#..AGTSU202011-202110

TIRE & DISC WHEEL-265/65R17, ALUMINUM

main42661-0KS60iGUN16#,TGN156..MA,TH;GGN155,GUN15#..(EPTSU,MASUV,THSUV)..H202006-202203

main42661-0KS70iGGN155,GUN165..IDNSU..H..(GCC,IDN);GUN15#,166,TGN156,166..(IDNSU,VNSUV)..H202007-202204

main42661-0KS90iGUN156..H..BZAGT202011-202110

TIRE & DISC WHEEL-265/60R18, ALUMINUM

main42661-0KT00iGUN156,166,TGN166..IND202101-202109

88723HLABEL, COOLER SERVICE CAUTION

main88723-0K230iGUN156,165,TGN166..VNSUV202007-202108

main88723-0K240iGUN156,166,TGN166..IND202101-202109

main88723-0K280iGUN156,165,TGN166..VNSUV202006-202204

main88723-0K290iGUN15#,16#..TH202006-202108

main88723-0K310iGGN155,GUN156,165,TGN156,16#..AGTSU202011-202110

main88723-0K330iGUN15#,16#,LAN155,TGN156..SA202009-202109

main88723-0K370iGUN15#,TGN156..MA202101-202110

main88723-0K400iGUN156,TGN156,166..PKN202104-202201

10 parts on this diagram · 2 diagrams in section
