THROTTLE LINK & VALVE LEVER (ATM)

0001 1A340E,A340F,A343E,A343F 0002 1A750E,A750F

3312

35501ROD SUB-ASSY, PARKING LOCK

main35501-60010iTGN51..4FC;TGN61..IDSUV..4FC..(GCC,IDN);KUN51,60,TGN61..(SUVW,THSUV)..4FC200501-200810

main35501-60020iGGN60..GEN200808-201107

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-60030iTGN51..4FC;TGN61..IDSUV..4FC..(GCC,IDN);KUN51,60,TGN61..(SUVW,THSUV)..4FC200501-200810

sub35505-26020

main35505-60040iGGN60..GEN200808-201107

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iGGN60..SUVW..5FC;GGN50,KUN5#,6#,TGN51,61..4FC,5FC200808

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002×2iGGN60..GEN200808-201107

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20025iGGN60..SUVW..5FC;GGN50,KUN5#,6#,TGN51,61..4FC,5FC200808

35556SHAFT, PARKING LOCK PAWL

main35556-30020iTGN51..4FC;TGN61..IDSUV..4FC..(GCC,IDN);KUN51,60,TGN61..(SUVW,THSUV)..4FC200501-200810

main35556-60020iGGN50..5FC;GGN60..ANCOM200507-200903

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iGGN60..GEN200808-201107

35557PAWL, PARKING LOCK

main35557-60020iKUN5#,6#,TGN51,61..4FC200808

main35557-60040iGGN50..5FC;GGN60..SUVW..5FC200808

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21002iKUN5#,6#,TGN51,61..4FC200808

main90949-03123iGGN60..GEN200808-201107

35561SHAFT, MANUAL VALVE LEVER

main35561-35010iKUN5#,6#,TGN51,61..4FC200808

main35561-60030iGGN50..5FC;GGN60..ANCOM200507-200903

35573LEVER, TRANSMISSION CONTROL SHAFT, LH

main35573-60020iGGN60..SUVW..5FC;GGN50,KUN5#,6#,TGN51,61..4FC,5FC200808

35595BRACKET, PARKING LOCK PAWL

main35595-60010iKUN5#,6#,TGN51,61..4FC200808

main35595-60030iGGN50..5FC;GGN60..SUVW..5FC200808

91611B0614

main91611-B0614

9413000802

main94130-00802

9451200800

main94512-00800

16 parts on this diagram · 2 diagrams in section
