THROTTLE LINK & VALVE LEVER (ATM)

0001 1U241E 0002 1U660E

35501ROD SUB-ASSY, PARKING LOCK

main35501-21010iACR50..4FC..(GCC,GEN)200601-201310

main35501-33020iGSR50..LHD200611-201605

main35501-42020iACR50..4FC201310-201605

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-21010iACR50..ARL200601-201605

main35505-33010iGSR50200611-200810

sub35505-33011

main35505-33011iGSR50200810-201204

35505BSPACER (FOR MANUAL VALVE LEVER)

main90560-20006iACR50200601-201605

35505GPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER)

main90254-04011iGSR50..ARL,GCC;GSR50..LHD..GEN;ACR50..4FC..(GCC,GEN)200601-201605

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35506-33020iGSR50201204-201605

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iGSR50..RHD..GEN200601-201605

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09001iACR50200601-201605

main90524-09002iGSR50..LHD200611-201605

35556SHAFT, PARKING LOCK PAWL

main35556-28020iACR50..4FC201310-201605

*345

main35556-28020iACR50..4FC201605

main35556-32030iACR50..ARL200601-201205

main35556-32030iACR50..4FC..(GCC,GEN)201204-201310

*344

main35556-33010iGSR50200611-201605

35557PAWL, PARKING LOCK

main35557-33020iGSR50200611-201203

sub35557-33021

main35557-33021iGSR50..RHD201203-201605

main35590-32010iACR50..4FC200601-201605

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90506-18077iACR50..4FC..(GCC,GEN)200601-201605

35558CLAMP, PAWL SHAFT

main35558-28020iACR50..4FC201310-201605

*345

main35558-28020iACR50..4FC201605

main35558-32010iACR50..4FC..(GCC,GEN)201204-201310

*344

main35558-32010iACR50..ARL200601-201205

main35558-33010iGSR50200611-201605

35561SHAFT, MANUAL VALVE LEVER

main35561-21010iACR50..4FC200601-201605

main35561-33020iGSR50200611-201204

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-28120iACR50..ARL200601-201205

sub35572-42020

main35572-28120iACR50..4FC..(GCC,GEN)201204-201310

*344

sub35572-42020

main35572-33020iGSR50200611-201605

main35572-42020iACR50..4FC201310-201605

*345

main35572-42020iACR50..4FC201605

35579PIN, PARKING LOCK PAWL

main35594-21010iACR50..4FC..(GCC,GEN)200601-201205

main35594-21010iACR50..4FC..(GCC,GEN)201204-201310

*344

main35594-28010iACR50..4FC201310-201605

*345

main35594-28010iACR50..4FC201605

35595BRACKET, PARKING LOCK PAWL

main35595-21010iACR50..ARL200601-201605

8401

9010506053

main90105-06053

9010506079

main90105-06079

9011908668

main90119-08668

9011908891

main90119-08891

9413000802

main94130-00802

9451200800

main94512-00800

22 parts on this diagram · 2 diagrams in section
