FRONT BUMPER & BUMPER STAY

0001 1 0002 1

52105STAY SUB-ASSY, FRONT BUMPER, RH

main52201-95701iKM20..WG;KM20..02S..ARL197910-198210

W/CHROME PLATED BUMPER

main52201-95705iKM20..08S198210-198508

W/CHROME PLATED BUMPER

52106STAY SUB-ASSY, FRONT BUMPER, LH

main52202-95701iKM20..WG;KM20..02S..ARL197910-198210

W/CHROME PLATED BUMPER

main52202-95704iKM20..08S198210-198508

W/CHROME PLATED BUMPER

52111BUMPER ASSY, FRONT

main52101-87405iKM20..TR197910-198101

main52101-87409iKM20..TR198101-198210

main52101-95704iKM20..(HRF,SRF)..(ARL,GEN)197910-198101

main52101-95705iKM20..SRF..EUR;KM20..HRF..VSP..EUR;KM20..HRF..(05S,07S)197910-198101

main52101-95706iKM20..VSG..02S198010-198101

W/HEADLAMP CLEANER

main52101-95707iKM20..4F;KM20..LHD..SRF..4H..EUR;KM20..HRF..VSP..4H..EUR;KM20..HRF..4H..(05S,07S)..EUR198103-198210

*WEG

main52101-95708iKM20..VSP..02S;KM20..(HRF,SRF)..(03S,05S,06S,07S,08S,09S)..STD198101-198210

main52101-95709iKM20..V4D..HRF..05S..EUR198101-198210

W/HEADLAMP CLEANER

main52101-95712iCM20,KM20,YM2#198210-198508

main52101-95714iCM20,KM20..HRF..4H..EUR198409-198508

main52101-95714iCM20..HRF..02S..EUR;KM20..HRF..05S..EUR198210-198409

W/HEADLAMP CLEANER

main52111-29395iKM20..WG;KM20..02S..ARL197910-198210

W/CHROME PLATED BUMPER

sub52111-95703

main52111-29465iKM20..WG..STD198103-198210

*WEG,W/CHROME PLATED BUMPER

sub52111-95706

main52111-29485iKM20..08S198210-198508

W/CHROME PLATED BUMPER

sub52111-95712

52112DEXTENSION, FRONT BUMPER, RH

main52011-29015iKM20..VSP..02S;KM20..03S,05S,06S,07S,08S,09S197910-198210

main52117-95701iCM20,KM20,YM2#198210-198508

52113DEXTENSION, FRONT BUMPER, LH

main52012-29015iKM20..VSP..02S;KM20..03S,05S,06S,07S,08S,09S197910-198210

main52118-95701iCM20,KM20,YM2#198210-198508

7554

9010906053

main90109-06053

9011208023

main90112-08023

9011908126

main90119-08126

9017906070

main90179-06070

9017908123

main90179-08123

9165140814

main91651-40814

9166560825

main91665-60825

9327016016

main93270-16016

9411040800

main94110-40800

15 parts on this diagram · 2 diagrams in section
