SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE & TRANSMISSION 0004 1ENGINE ROOM 0005 1ENGINE ROOM 0006 1ENGINE ROOM RELAY BLOCK 0007 1ENGINE ROOM RELAY BLOCK 0008 1ENGINE ROOM RELAY BLOCK 0009 1COWL 0010 1COWL 0011 1INSTRUMENT PANEL 0012 1INSTRUMENT PANEL 0013 1COSOLE BOX 0014 1COSOLE BOX 0015 1STEERING 0016 1SEAT 0017 1SEAT 0018 1DOOR & ROOF 0019 1FLOOR & BACK DOOR

82715BRACKET,WIRING HARNESS CLAMP

main82715-0Z150iZSG10..LHD..SAP202110-202411

main82715-12X60iZSG10..LHD..THP;ZVG10..LHD..THP..E202007-202412

82715WBRACKET, WIRING HARNESS CLAMP

main82715-44510iZSG10..MAP..G¥200202007-202512

main82729-20040iMXGA10,ZVG10..BZP¥220202010-202412

82715XBRACKET, WIRING HARNESS CLAMP, NO.2

main82715-0Z190iZSG10,ZVG10..TWP202010-202410

main82715-0Z410iMXGA10,ZVG10..BZP202103-202412

main82715-F4300iZSG10..TH202007-202512

82715YBRACKET, WIRING HARNESS CLAMP, NO.3

main82715-F4290iZSG10..TH202007-202512

main8946A-0A050iZVG10..SAP,TWP;ZSG10..LHD..(G,N)..GEN;ZSG10..(SAP,TWP)..(E,M);ZSG10..(G,J,N)..(GCC,SA,TAIW)202010-202411

main8946A-0A060iMXGA10,ZVG10..BZP202103-202412

main8946A-0A090iZSG10,ZVG10..E..MA202112-202411

82715ZBRACKET, WIRING HARNESS CLAMP

main82715-0Z420iMXGA10202103-202412

main82715-10310iZVG10..TWP¥770202007-202412

main82715-10410iZSG10..SAP;ZSG10..MAP..G202007-202512

main82715-F4190iZVG10..SA202110-202411

main8946A-0A080iZVG10..MA202112-202410

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-12060iZSG10..MAP..G;ZSG10,ZVG10..SAP¥1,970202007-202512

84540SWITCH ASSY, NEUTRAL START

main84540-12240iMXGA10¥7,600202103-202412

main84540-52070iZSG10..TWP..G;ZSG10..(MAP,TWP)..(E,J,M,N)¥7,600202007-202512

89429FSENSOR, TEMPERATURE

main89429-12010iZSG10..MA¥3,380202007-202512

89465SENSOR, OXYGEN

main89465-10080iZVG10..BZP;ZSG10,ZVG10..MA¥6,400202007-202512

89467BSENSOR, AIR FUEL RATIO

main89467-02220iZSG10..SAP202110-202411

main89467-12260iZSG10..TH¥9,900202007-202512

main89467-12280iMXGA10¥9,900202103-202412

main89467-12340iZVG10..BZP..E..GEN¥9,900202103-202412

PARAGUAY SPEC

main89467-47030iZVG10..MA;ZVG10..BZP..(AGT,GEN)¥9,900202007-202412

main89467-47040iMXGA10¥9,900202501

89615SENSOR, KNOCK CONTROL

main89615-02020iZSG10..IDN¥10,600202106-202411

MARK 89615-02020

main89615-02020iZVG10..SA¥10,600202110-202411

(L)

main89615-20090iZSG10..TH¥2,370202007-202512

main89615-20090iZSG10..MA¥2,370202106-202411

MARK 89615-20090

main89615-20090iZVG10..SA¥2,370202110-202411

(J)

main89615-78010iMXGA10¥10,600202209-202403

MARK 89615-78010

90105T0178

main90105-T0178

90105W0086

main90105-W0086¥100

90105W0140

main90105-W0140¥80

90119W0037

main90119-W0037¥60

9043012221

main90430-12221¥200

9155180835

main91551-80835¥80

9155381014

main91553-81014¥100

9165140620

main91651-40620¥70

9167380616

main91673-80616¥60

20 parts on this diagram · 19 diagrams in section
