BACK DOOR LOCK & HANDLE

0001 1W/O(POWER BACK DOOR) 0002 1W(POWER BACK DOOR)

68810CHINGE ASSY, BACK DOOR, RH

main68810-0A030iZSG10,ZVG10..MA202007-202111

main68810-0A060iZSG10,ZVG10..TWP202010-202410

main68810-0A080iMXGA10,ZVG10..BZP202201-202403

main68810-0A200iZSG10,ZVG10..SAP202110-202411

main68810-0A260iZSG10..LHD..E..GEN;ZSG10..RHD..THP..GEN;ZSG10..(E,N)..(MA,VN);ZVG10..(MAP,THP)..(E,G,R)202401

PAD T=1.0

main68810-0A270iZSG10..LHD..E..GEN;ZSG10..RHD..THP..GEN;ZSG10..(E,N)..(MA,VN);ZVG10..(MAP,THP)..(E,G,R)202401

PAD T=1.5

main68810-0A280iZSG10..TH202401-202512

PAD T=2.0

main68810-0A310iZSG10,ZVG10..TWP202410

main68810-0A330iMXGA10,ZVG10..BZP202501

main68810-0A350iZSG10,ZVG10..SAP202411

68820CHINGE ASSY, BACK DOOR, LH

main68810-0A030iZSG10,ZVG10..MAP..E202007-202410

main68810-0A060iZSG10,ZVG10..TWP202010-202410

main68810-0A080iMXGA10,ZVG10..BZP202103-202112

main68810-0A200iZSG10,ZVG10..SAP202110-202411

main68810-0A260iZSG10..LHD..E..GEN;ZSG10..RHD..THP..GEN;ZSG10..(E,N)..(MA,VN);ZVG10..(MAP,THP)..(E,G,R)202401

PAD T=1.0

main68810-0A270iZSG10..LHD..E..GEN;ZSG10..RHD..THP..GEN;ZSG10..(E,N)..(MA,VN);ZVG10..(MAP,THP)..(E,G,R)202401

PAD T=1.5

main68810-0A280iZSG10..TH202401-202512

PAD T=2.0

main68810-0A310iZSG10,ZVG10..TWP202410

main68810-0A330iMXGA10,ZVG10..BZP202501

main68810-0A350iZSG10,ZVG10..SAP202411

68838PAD, BACK DOOR HINGE, NO.1

main68838-0A040×2iZSG10,ZVG10..TWP202010-202410

T=1.0

main68838-0A050×2iZSG10,ZVG10..TWP202010-202410

T=1.5

main68838-0A060×2iZSG10,ZVG10..TWP202010-202410

T=2.0

main68838-0A190×2iZSG10,ZVG10..SAP202110-202411

T=1.0

main68838-0A200×2iZSG10,ZVG10..SAP202110-202411

T=1.5

main68838-0A210×2iZSG10,ZVG10..SAP202110-202411

T=2.0

main68838-42010×2iZSG10..TWP..G;ZVG10..TWP..N;ZSG10..RHD..THP..GEN;ZSG10..(E,M,N)..(MA,TAIW,VN);ZVG10..(MAP,THP,TWP)..(E,G,L,M,R);ZSG10..LHD..(THP,TWP)..(E,J)..(GCC,GEN)202401

T=1.0

main68838-42020×2iZSG10..TH202401-202512

T=1.5

main68838-42030×2iZSG10..TWP..G;ZVG10..TWP..N;ZSG10..RHD..THP..GEN;ZSG10..(E,M,N)..(MA,TAIW,VN);ZVG10..(MAP,THP,TWP)..(E,G,L,M,R);ZSG10..LHD..(THP,TWP)..(E,J)..(GCC,GEN)202401

T=2.0

main68838-F4050×2iZSG10,ZVG10..MA202007-202111

T=1.5

68945BRACKET, BACK DOOR DAMPER STAY, UPPER RH

main68945-0A010iZSG10..N..VN;ZVG10..E..PH;ZVG10..THP..N;ZVG10..THP..(E,G)..GEN;ZSG10..THP..(GEN,PH,TH)202007-202402

main68945-0A020iZSG10,ZVG10..(MAP,TWP)..E..(MA,TAIW)202007-202410

main68945-0A050iMXGA10,ZVG10..BZP202103-202112

main68945-0A120iZSG10,ZVG10..SAP202110-202411

SOUTH AFRICA PRODUCT

main68945-0A140iMXGA10;ZVG10..BZP..G;ZVG10..BZP..E..GEN202501

main68945-0A150iMXGA10..E;ZVG10..BZP..E..GEN202501

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

main68945-0A160iZSG10..LHD..E..GEN;ZVG10..G..(IDN,TH);ZSG10..(E,N)..(MA,VN);ZVG10..(MAP,THP,TWP)..(E,L,R)..(GEN,MA,PH,TAIW,TH,VN)202401

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

main68945-0A170iZVG10..TWP..N;ZSG10..N..TAIW;ZSG10..RHD..THP;ZSG10..TWP..(G,M);ZSG10,ZVG10..(E,J)..GCC;ZVG10..(THP,TWP)..(G,M)..(GCC,GEN,PH,TAIW)202401

main68945-0A200iZSG10..SAP..GEN;ZSG10,ZVG10..(G,N)..SA202411

main68945-0A210supersedes 68945-0A200iZSG10,ZVG10..G..SA202411

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

68946BRACKET, BACK DOOR DAMPER STAY, UPPER LH

main68946-0A010iZSG10,ZVG10..E..(IDN,VN)202007-202212

main68946-0A020iZSG10..MAP..G202007-202411

main68946-0A050iMXGA10,ZVG10..BZP202201-202403

main68946-0A120iZSG10,ZVG10..SAP202110-202411

SOUTH AFRICA PRODUCT

main68946-0A140iMXGA10;ZVG10..BZP..G;ZVG10..BZP..E..GEN202404-202412

main68946-0A150iMXGA10..E;ZVG10..BZP..E..GEN202501

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

main68946-0A160iZSG10..LHD..E..GEN;ZVG10..G..(IDN,TH);ZSG10..(E,N)..(MA,VN);ZVG10..(MAP,THP,TWP)..(E,L,R)..(GEN,MA,PH,TAIW,TH,VN)202401

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

main68946-0A170iZVG10..TWP..N;ZSG10..N..TAIW;ZSG10..RHD..THP;ZSG10..TWP..(G,M);ZSG10,ZVG10..(E,J)..GCC;ZVG10..(THP,TWP)..(G,M)..(GCC,GEN,PH,TAIW)202401

main68946-0A200iZSG10..SAP..GEN;ZSG10,ZVG10..(G,N)..SA202411

main68946-0A210supersedes 68946-0A200iZSG10,ZVG10..E..SA202411-202602

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

68947BRACKET, BACK DOOR DAMPER STAY, LOWER RH

main68947-0A010iZSG10..MAP..G202007-202411

main68947-0A050iMXGA10,ZVG10..BZP202103-202112

main68947-0A100iZSG10,ZVG10..SAP202110-202411

main68947-0A130iMXGA10,ZVG10..BZP202501

main68947-0A150iZSG10..TWP..G;ZVG10..TWP..N;ZSG10..RHD..THP;ZSG10..(E,M,N)..(MA,TAIW,VN);ZVG10..(MAP,THP,TWP)..(E,G,L,M,R);ZSG10..LHD..(THP,TWP)..(E,J)..(GCC,GEN)202401

main68947-0A170iZSG10,ZVG10..SAP202411

68948BRACKET, BACK DOOR DAMPER STAY, LOWER LH

main68948-0A010iZSG10..MAP..G202007-202411

main68948-0A050iMXGA10,ZVG10..BZP202103-202112

main68948-0A060iMXGA10,ZVG10..BZP202404-202412

main68948-0A120iZSG10,ZVG10..SAP202110-202411

main68948-0A150iZSG10..TWP..G;ZVG10..TWP..N;ZSG10..RHD..THP;ZSG10..(E,M,N)..(MA,TAIW,VN);ZVG10..(MAP,THP,TWP)..(E,G,L,M,R);ZSG10..LHD..(THP,TWP)..(E,J)..(GCC,GEN)202401

main68948-0A170iZSG10,ZVG10..SAP202411

68950CSTAY ASSY, BACK DOOR, RH

main68950-0A010iZVG10..L202007-202205

main68950-0A030iMXGA10,ZVG10..BZP202201-202403

main68950-0A100iZSG10,ZVG10..E..SA202401-202602

main68950-0A110iMXGA10;ZVG10..BZP..G;ZVG10..BZP..E..GEN202404-202412

68960BSTAY ASSY, BACK DOOR, LH

main68960-0A010iZVG10..E..GCC;ZSG10,ZVG10..TWP..(G,J,M,N)202007-202410

main68960-0A030iMXGA10,ZVG10..BZP202103-202112

main68960-0A100iZSG10..TH202401-202512

main68960-0A110iMXGA10;ZVG10..BZP..G;ZVG10..BZP..E..GEN202404-202412

69350PLOCK ASSY, BACK DOOR, W/COURTESY LAMP SWITCH

main69350-0A070iZVG10..(E,G)..(IDN,TH)202011-202402

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

main69350-0K190iZSG10,ZVG10..E..(IDN,VN)202007-202212

main69350-42060iZSG10..MA;ZVG10..(E,G)..(IDN,MA,TH)202007-202011

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

main69350-42070iMXGA10,ZVG10..BZP202010-202112

main69350-78090supersedes 69350-0K190iZSG10,ZVG10..(E,R)..(AGT,BZ,MA)202404

BACK DOOR OPENER SWITCH-POWER & HANDS FREE

69430CSTRIKER ASSY, BACK DOOR LOCK

main69430-0A030iZSG10,ZVG10..SAP202110-202411

main69430-28050iZVG10..TWP;ZSG10..J..GCC;ZSG10..N..TAIW;ZSG10..TWP..(G,M)202404

main69430-F4020iZSG10,ZVG10..MAP..E202007-202410

9010506184

main90105-06184

9010508148

main90105-08148

90105T0054

main90105-T0054

90105T0167

main90105-T0167

9011906897

main90119-06897

90119T0122

main90119-T0122

90119T0396

main90119-T0396

9014880066

main90148-80066

90148T0015

main90148-T0015

9018208009

main90182-08009

90182T0038

main90182-T0038

9155110816

main91551-10816

9155180816

main91551-80816

24 parts on this diagram · 2 diagrams in section
