REAR DISC BRAKE CALIPER & DUST COVER

04466PAD KIT, DISC BRAKE, REAR

main04466-42080iAXUH80,MXUA80202009-202309

MARK NBK 478-XA5

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-42100iAXUH80,MXUA80202009-202309

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04946-33090iAXUH80,MXUA80202009-202309

04948FITTING KIT, DISC BRAKE, REAR

main04948-12071iAXUH80,MXUA80202204-202309

main04948-33060iAXUH80,MXUA80202009-202203

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010iMXUA80..G202009-202309

4601

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-20010iAXUH80,MXUA80202009-202309

47721DBOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)

main90015-AA603iAXUH80,MXUA80202009-202309

*8-1.00PX23-12.5

sub90016-AA614

47769ABUSH, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47769-50010iAXUH80,MXUA80202009-202309

47803COVER SUB-ASSY, DISC BRAKE DUST, REAR RH

main47803-33010iAXUH80,MXUA80202009-202309

47804COVER SUB-ASSY, DISC BRAKE DUST, REAR LH

main47804-33010iMXUA80..G202009-202309

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90105-12174iAXUH80,MXUA80202009-202309

47814PIN, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47814-78010iAXUH80,MXUA80202009-202309

47815PIN, REAR CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)

main47815-78010iAXUH80,MXUA80202009-202309

47821MOUNTING, REAR DISC BRAKE CYLINDER, RH

main47821-10030iAXUH80,MXUA80202009-202309

47822MOUNTING, REAR DISC BRAKE CYLINDER, LH

main47822-10030iAXUH80,MXUA80202009-202309

47830CYLINDER ASSY, DISC BRAKE, REAR RH

main47830-42090iAXUH80,MXUA80202009-202309

47831PISTON, REAR DISC BRAKE

main47831-48130iAXUH80,MXUA80202009-202309

47850CYLINDER ASSY, DISC BRAKE, REAR LH

main47850-42080iAXUH80,MXUA80202009-202309

47875RBOOT, BUSH DUST(FOR REAR DISC BRAKE)

main47875-33270iAXUH80,MXUA80202009-202309

20 parts on this diagram · 1 diagram in section
