OIL PUMP, OIL COOLER & PIPE (MTM)
32906GTUBE SUB-ASSY, OIL COOLER
32913ABRACKET, TRANSMISSION OIL COOLER
32920CCOOLER ASSY, OIL W/HOSE
32941PHOSE, OIL COOLER INLET, NO.1
32941QHOSE, OIL COOLER INLET, NO.2
32942KHOSE, OIL COOLER OUTLET, NO.1
32942LHOSE, OIL COOLER OUTLET, NO.2
32942MCONNECTOR, TUBE
32943KHOSE, TRANSMISSION OIL COOLER
32943LELBOW
33470PUMP ASSY, MANUAL TRANSMISSION OIL
33576CBRACKET, BACK-UP LAMP SWITCH
9030111006
main90301-11006
9046716022
main90467-16022
9155180816
main91551-80816
9155180830
main91551-80830
16 parts on this diagram · 1 diagram in section
