CAUTION PLATE (EXTERIOR & INTERIOR)

0001 1ENGINE ROOM, EXTERIOR(1/3) 0002 1EXTERIOR(2/3), INTERIOR 0003 1EXTERIOR(3/3)

11278BLABEL, ENGINE EMISSION COMPLIANCE INFORMATION

main11278-16050i3UZFE..UCF30..RHD..EUR200008-200608

11289BLABEL, SPARK PLUG NOTICE

main11289-50010i3UZFE..UCF30..ARL,EUR200008-200608

11296CLABEL, ENGINE SERVICE INFORMATION

main11296-50290i3UZFE..UCF30..GCC;3UZFE..UCF30..RHD..EUR200107-200608

TYPE B:REFER ILLUST.

main11296-50350i3UZFE..UCF30..GCC200008-200411

TYPE A:REFER ILLUST.

main11296-50360i3UZFE..UCF30..LHD..EUR200008-200608

11297CLABEL, ENGINE SERVICE INFORMATION, NO.2

main11297-50010i3UZFE..UCF30200008-200608

11298BLABEL, EMISSION CONTROL INFORMATION

main11298-50300i3UZFE..UCF30200008-200307

13564LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010i3UZFE..UCF30200008-200307

16448APLATE, RADIATOR CAUTION

main16448-50240i3UZFE..UCF30..EUR,GCC200107-200608

16793ELABEL, COOLING FAN CAUTION

main16793-46010i3UZFE..UCF30200008-200410

AIR CLEANER INLET

main16793-50010i3UZFE..UCF30200411-200608

AIR CLEANER INLET

86995ELABEL, CAUTION

main88723-20081iUCF30200008-200608

FAN SHROUD

sub16793-31070

9 parts on this diagram · 3 diagrams in section
