DISC WHEEL & WHEEL CAP

Parts diagram
04423FITTING KIT, TIRE PRESSURE MONITOR OR BALANCER VALVE
main04423-33030i200607-201112
sub04423-33060
main04423-33030i200801-201112
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub04423-33060
main04423-35020i200602-200604
main04423-42010i200604-200607
04423BFITTING KIT, TIRE PRESSURE MONITOR OR BALANCER VALVE(SPARE)
main04423-33030i200809-201112
SOUTH AFRICA SPEC
sub04423-33060
main04423-33030i200709-200801
sub04423-33060
42601WHEEL, DISC
main42601-30040i200602-200909
18X8J, #,NEW ZEALAND SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200602-200909
18X8J, #,AUSTRALIA SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200709-200909
18X8J, #,TAIWAN SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200809-200909
18X8J, #,SOUTH AFRICA SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200809-200909
18X8J, #,HONG KONG SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200809-200909
18X8J, #,SINGAPORE SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200809-200909
18X8J, #,TURKEY SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200809-200909
18X8J, #,CHINA SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200809-200909
18X8J, #,ISRAEL SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30050i200709-200909
18X8J, #,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE F:REFER ILLUST.
main42601-30050i200602-200909
18X8J, #,TYPE F:REFER ILLUST.
main42601-30070i200804-200909
18X8J,RUSSIA SPEC,TYPE F:REFER ILLUST.
main42601-30080i200909-201112
18X8J, #,HONG KONG SPEC,TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201005
18X8J, #,CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201112
18X8J, #,SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201112
18X8J, #,SOUTH AFRICA SPEC,TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201112
18X8J, #,AUSTRALIA SPEC,TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201112
18X8J, #,SINGAPORE SPEC,TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201112
18X8J, #,NEW ZEALAND SPEC,TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201112
18X8J, #,TAIWAN SPEC,TYPE G:REFER ILLUST.
sub42601-30090
main42601-30090i200909-201112
18X8J, #,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30091
main42601-30090i201101-201112
18X8J, #,UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30091
main42601-30090i200909-201112
18X8J, #,TYPE G:REFER ILLUST.
sub42601-30091
main42601-30100i200909-201112
18X8J, #,RUSSIA SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30101
main4261A-30020i200909-201002
17X7.5J, #,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J,TYPE D:REFER ILLUST.
sub4261A-30110
main4261A-30110i201003-201112
17X7.5J, #,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J,TYPE D:REFER ILLUST.
sub4261A-30111
42601AWHEEL, DISC (FOR SPARE)
main42601-30040i200809-200909
18X8J, #,ISRAEL SPEC
sub42601-30050
main42601-30040i200809-200909
18X8J, #,SINGAPORE SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200809-200909
18X8J, #,SOUTH AFRICA SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30040i200809-200909
18X8J, #,TURKEY SPEC
sub42601-30050
main42601-30040i200809-200909
18X8J, #,CHINA SPEC,TYPE F:REFER ILLUST.
sub42601-30050
main42601-30070i200809-200909
18X8J,RUSSIA SPEC,TYPE F:REFER ILLUST.
main42601-30080i200909-201112
18X8J, #,SOUTH AFRICA SPEC,TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201101
18X8J, #,SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201005
18X8J, #,CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30090
main42601-30080i200909-201112
18X8J, #,SINGAPORE SPEC,TYPE G:REFER ILLUST.
sub42601-30090
main42601-30090i200909-201101
18X8J, #,UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30091
main42601-30090i201006-201112
18X8J, #,CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30091
main42601-30090i201007-201101
18X8J, #,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30091
main42601-30100i200909-201101
18X8J, #,RUSSIA SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE G:REFER ILLUST.
sub42601-30101
main42611-30A60i200709-200908
17X4T,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPEC:REFER ILLUST.
main42611-30A60i200602-200908
17X4T,TYPE C:REFER ILLUST.
main42611-53320i200909-201112
17X4T,TYPE C:REFER ILLUST.
sub42611-53321
main42611-53320i200909-201112
17X4T,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPEC:REFER ILLUST.
sub42611-53321
42601CNUT, HUB (FOR AXLE)
main90942-01033i200602-201112
42603ORNAMENT SUB-ASSY, WHEEL HUB
main42603-30540i200602-200909
*ALU,TYPE A:REFER ILLUST.
main42603-30590i200909
*CHR,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J,TYPE A:REFER ILLUST.
main42603-30660i200802-200909
*ALU,RUSSIA SPEC,TYPE A:REFER ILLUST.
main42603-50300i200909
*ALU,TYPE A:REFER ILLUST.
main42603-50340i200909
*ALU,RUSSIA SPEC,TYPE A:REFER ILLUST.
42603EGARNISH SUB-ASSY, WHEEL HUB
main42603-30620i200602-200709
sub4260B-30010
main4260B-30010i200809-200909
SOUTH AFRICA SPEC
main4260B-30010i200809-200909
TURKEY SPEC
main4260B-30010i200809-200909
CHINA SPEC
main4260B-30010i200809-200909
ISRAEL SPEC
main4260B-30010i200809-200909
SINGAPORE SPEC
main4260B-30010i200709-200909
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main4260B-30020i200804-200909
RUSSIA SPEC
main4260B-30030i200909-201111
SPARE TIRE-GROUND TIRE(ALUMI)
main4260B-30030i200909-201111
CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main4260B-30030i200909-201111
UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main4260B-30030i200909-201111
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main4260B-30030i200909-201111
SINGAPORE SPEC
main4260B-30030i200909-201111
SOUTH AFRICA SPEC
main4260B-30040i200909-201111
RUSSIA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
42607VALVE SUB-ASSY, TIRE PRESSURE MONITOR
main42607-30040i200602-200607
sub42607-30041
main42607-33021i200709-201112
TAIWAN SPEC
sub42607-33022
main42607-50010i200709-200908
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub42607-50011
main42607-50010i200607-200709
sub42607-50011
main42607-50011i200909-201112
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub42607-50012
42607AVALVE SUB-ASSY, TIRE PRESSURE MONITOR (FOR SPARE)
main42607-50010i200809-200908
ISRAEL SPEC
sub42607-50011
main42607-50010i200809-200908
SOUTH AFRICA SPEC
sub42607-50011
main42607-50010i200809-200908
TURKEY SPEC
sub42607-50011
main42607-50010i200809-200908
RUSSIA SPEC
sub42607-50011
main42607-50011i200909
RUSSIA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub42607-50012
main42607-50011i200909
SPARE TIRE-GROUND TIRE(ALUMI)
sub42607-50012
main42607-50011i200909
SOUTH AFRICA SPEC
sub42607-50012
42607BVALVE SUB-ASSY, TIRE PRESSURE BALANCER
main42607-35020i200909-201001
CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub90942-05041
main42607-35020i200909-201001
UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub90942-05041
main42607-35020i200809-201001
SINGAPORE SPEC
sub90942-05041
main42607-35020i200602-201001
NEW ZEALAND SPEC
sub90942-05041
main42607-35020i200602-201001
AUSTRALIA SPEC
sub90942-05041
main42607-35020i200809-200909
CHINA SPEC
sub90942-05041
main42607-35020i200809-201001
HONG KONG SPEC
sub90942-05041
42607CVALVE SUB-ASSY, TIRE PRESSURE BALANCER (FOR SPARE)
main42607-35020i200909-201001
CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub90942-05041
main42607-35020i200909-201001
UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub90942-05041
main42607-35020i200809-201001
SINGAPORE SPEC
sub90942-05041
main42607-35020i200809-200909
CHINA SPEC
sub90942-05041
42611GVALVE (FOR TUBELESS TIRE)
main90942-05028i201001
AUSTRALIA SPEC,TYPE B:REFER ILLUST.
main90942-05028i201001
CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE B:REFER ILLUST.
main90942-05028i201001
UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE B:REFER ILLUST.
main90942-05028i201001
HONG KONG SPEC,TYPE B:REFER ILLUST.
main90942-05028i201001
SINGAPORE SPEC,TYPE B:REFER ILLUST.
main90942-05028i201001
NEW ZEALAND SPEC,TYPE B:REFER ILLUST.
main90942-05028i201007
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI),TYPE B:REFER ILLUST.
42611JVALVE (FOR TUBELESS TIRE SPARE)
main90942-05009i200709-201112
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05009i200602-200709
TYPE A:REFER ILLUST.
main90942-05028i201001-201112
SINGAPORE SPEC
main90942-05028i201001-201112
CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05028i201001-201112
UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05028i201007-201112
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
42611UCAP, TIRE VALVE
main90942-05029i200809-201111
SINGAPORE SPEC
main90942-05029i200602-201111
NEW ZEALAND SPEC
main90942-05029i200602-201111
AUSTRALIA SPEC
main90942-05029i200809-200909
CHINA SPEC
main90942-05029i200809-201111
HONG KONG SPEC
main90942-05029i200909-201111
CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05029i200909-201111
UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05029i201007-201111
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05037i200602-200709
main90942-05037i200709-201111
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
42611WCAP, TIRE VALVE (FOR SPARE)
main90942-05029i200809-201111
SINGAPORE SPEC
main90942-05029i200809-200909
CHINA SPEC
main90942-05029i201007-201111
SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05029i200909-201111
UKRAINE SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05029i200909-201111
CHINA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05037i200809-200909
RUSSIA SPEC
main90942-05037i200809-200909
TURKEY SPEC
main90942-05037i200809-200909
ISRAEL SPEC
main90942-05037i200809-201111
SOUTH AFRICA SPEC
main90942-05037i200909-201111
RUSSIA SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main90942-05037i200909-201111
SPARE TIRE-GROUND TIRE(ALUMI)
42618RETAINER, WHEEL CAP
main42618-24010i200709
TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J
main42618-24010i200602-200709
42652TIRE
main42652-24333i200602-200606
245/40ZR18,*B/S,TIRE & DISK WHEEL-245/40R18 8JJ RUN FLAT
sub42652-24334
main42652-24333i200602-200606
245/40ZR18,*B/S,TIRE & DISK WHEEL-245/40R18 8JJ RUN FLAT&SPARE TIRE-WITHOUT
sub42652-24334
main42652-24333i200709-200712
245/40ZR18,*B/S,STABILIZER-WITH(ACTIVE STABILIZER SUSPENSION)&TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J
sub42652-24334
main42652-24333i200607-200707
245/40ZR18,*B/S,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT&SPARE TIRE-WITHOUT
sub42652-24334
main42652-24333i200607-200707
245/40ZR18,*B/S,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT
sub42652-24334
main42652-24341i200607-200708
245/40ZR18,*D/L,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT&SPARE TIRE-WITHOUT
sub42652-24343
main42652-24341i200602-200606
245/40ZR18,*D/L,TIRE & DISK WHEEL-245/40R18 8JJ RUN FLAT&SPARE TIRE-WITHOUT
sub42652-24343
main42652-24341i200607-200708
245/40ZR18,*D/L,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT
sub42652-24343
main42652-24341i200602-200606
245/40ZR18,*D/L,TIRE & DISK WHEEL-245/40R18 8JJ RUN FLAT
sub42652-24343
main42652-24343i200909-200911
245/40ZR18,*D/L,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J&SPARE TIRE-WITHOUT
sub42652-24344
main42652-24343i200709-200909
245/40ZR18,*D/L,STABILIZER-WITH(ACTIVE STABILIZER SUSPENSION)&TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J
sub42652-24344
main42652-24344i200912-201112
245/40RF18,*D/L,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J&SPARE TIRE-WITHOUT
main42652-24351i200607-200709
245/40ZR18,*D/L,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT
main42652-24351i200602-200606
245/40ZR18,*D/L,TIRE & DISK WHEEL-245/40R18 8JJ RUN FLAT
main42652-24351i200602-200606
245/40ZR18,*D/L,TIRE & DISK WHEEL-245/40R18 8JJ RUN FLAT&SPARE TIRE-WITHOUT
main42652-24351i200607-200709
245/40ZR18,*D/L,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT&SPARE TIRE-WITHOUT
main42652-24353i200709-200809
245/40ZR18,*D/L,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J&SPARE TIRE-WITHOUT
sub42652-24354
main42652-24353i200709-200911
245/40ZR18,*D/L,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J
sub42652-24354
main42652-24354i200912-201112
245/40RF18,*D/L,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J
main42652-24372i200607-200707
245/40R18,*B/S,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT&SPARE TIRE-WITHOUT
sub42652-24373
main42652-24372i200607-200707
245/40R18,*B/S,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT
sub42652-24373
main42652-24372i200709-200712
245/40R18,*B/S,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J
sub42652-24373
main42652-24372i200709-200712
245/40R18,*B/S,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J&SPARE TIRE-WITHOUT
sub42652-24373
main42652-24372i200602-200606
245/40R18,*B/S,TIRE & DISK WHEEL-245/40R18 8JJ RUN FLAT
sub42652-24373
main42652-24372i200602-200606
245/40R18,*B/S,TIRE & DISK WHEEL-245/40R18 8JJ RUN FLAT&SPARE TIRE-WITHOUT
sub42652-24373
main42652-30801i200909-201112
225/50R17,*D/L,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J
main42652-30811i200909-201012
225/50R17,*D/L,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J
sub42652-30812
main42652-30812i201101-201112
225/50R17,*D/L,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J
main42652-30830i200602-200708
245/40R18,*D/L
sub42652-30831
main42652-30830i200602-200708
245/40R18,*D/L,AUSTRALIA SPEC
sub42652-30831
main42652-30830i200602-200708
245/40R18,*D/L,NEW ZEALAND SPEC
sub42652-30831
main42652-30831i200709-201112
245/40R18,*D/L
main42652-30840i200602-200708
245/40R18,*D/L
sub42652-30841
main42652-30841i200709-201012
245/40R18,*D/L
sub42652-30842
main42652-30841i200709-201012
245/40R18,*D/L,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
sub42652-30842
main42652-30842i201101-201112
245/40R18,*D/L
main42652-30842i201101-201112
245/40R18,*D/L,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main42652-30A31i200909-201112
225/50R17,*Y/H,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J
main42652-30A51i200909-201012
225/50R17,*Y/H,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J
sub42652-30A52
main42652-30A52i201101-201112
225/50R17,*Y/H,TIRE & DISC WHEEL-225/50R17 SUMMER TIRE 7.5J
main42652-30A60i200602-200704
245/40R18,*Y/H
sub42652-30A61
main42652-30A60i200602-200704
245/40R18,*Y/H,NEW ZEALAND SPEC
sub42652-30A61
main42652-30A60i200602-200704
245/40R18,*Y/H,AUSTRALIA SPEC
sub42652-30A61
main42652-30A61i200705-201112
245/40R18,*Y/H
main42652-30A70i200602-200704
245/40R18,*Y/H
sub42652-30A71
main42652-30A71i200705-201012
245/40R18,*Y/H
sub42652-30A72
main42652-30A72i201101-201112
245/40R18,*Y/H
main42652-30C10i200607-201111
245/40R18,MICHELIN
main42652-30C20i200607-201112
245/40R18,MICHELIN
main42652-30C20i200709-201112
245/40R18,MICHELIN,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main42652-30D10i200708-200709
245/40R18,*B/S,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT&SPARE TIRE-WITHOUT
sub42652-30D11
main42652-30D10i200708-200709
245/40R18,*B/S,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT
sub42652-30D11
main42652-30D10i200712-200911
245/40R18,*B/S,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J
sub42652-30D11
main42652-30D10i200712-200809
245/40R18,*B/S,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J&SPARE TIRE-WITHOUT
sub42652-30D11
main42652-30D11i200912-201112
245/40RF18,*B/S,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J
main42652-30D20i200708-200709
245/40R18,*B/S,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT
sub42652-30D21
main42652-30D20i200708-200709
245/40R18,*B/S,TIRE & DISK WHEEL-245/40R18 8J RUN FLAT&SPARE TIRE-WITHOUT
sub42652-30D21
main42652-30D20i200712-200909
245/40R18,*B/S,STABILIZER-WITH(ACTIVE STABILIZER SUSPENSION)&TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J
sub42652-30D21
main42652-30D20i200909-200911
245/40R18,*B/S,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J&SPARE TIRE-WITHOUT
sub42652-30D21
main42652-30D21i200912-201112
245/40RF18,*B/S,TIRE & DISC WHEEL-245/40R18 RUN FLAT SUMMER TIRE 8J&SPARE TIRE-WITHOUT
42652ATIRE (FOR SPARE)
main42652-30831i200809-201112
245/40R18,*D/L,SINGAPORE SPEC
main42652-30831i200809-201112
245/40R18,*D/L,SOUTH AFRICA SPEC
main42652-30841i200909-201012
245/40R18,*D/L,SPARE TIRE-GROUND TIRE(ALUMI)
sub42652-30842
main42652-30841i200809-200909
245/40R18,*D/L,TURKEY SPEC
sub42652-30842
main42652-30841i200809-200909
245/40R18,*D/L,ISRAEL SPEC
sub42652-30842
main42652-30842i201101-201112
245/40R18,*D/L,SPARE TIRE-GROUND TIRE(ALUMI)
main42652-30A61i200809-201112
245/40R18,*Y/H,SOUTH AFRICA SPEC
main42652-30A61i200809-201112
245/40R18,*Y/H,SINGAPORE SPEC
main42652-30A71i200809-200909
245/40R18,*Y/H,ISRAEL SPEC
sub42652-30A72
main42652-30A71i200809-200909
245/40R18,*Y/H,TURKEY SPEC
sub42652-30A72
main42652-30A71i200909-201012
245/40R18,*Y/H,SPARE TIRE-GROUND TIRE(ALUMI)
sub42652-30A72
main42652-30A72i201101-201112
245/40R18,*Y/H,SPARE TIRE-GROUND TIRE(ALUMI)
main42652-30C00i200709-200809
T155/70D17,*T/Y,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main42652-30C00i200602-200809
T155/70D17,*T/Y
main42652-30C00i200809-201112
T155/70D17,*T/Y,TAIWAN SPEC
main42652-30C00i200809-201112
T155/70D17,*T/Y,NEW ZEALAND SPEC
main42652-30C00i200809-201112
T155/70D17,*T/Y,AUSTRALIA SPEC
main42652-58050i200709-201112
T155/70D17,*D/L,SERBIA,BOSNIA & HERZEGOVINA,BELARUS SPEC&SPARE TIRE-GROUND TIRE(ALUMI)
main42652-58050i200610-201112
T155/70D17,*D/L

18 parts on this diagram · 2 diagrams in section

DISC WHEEL & WHEEL CAP — Toyota Parts Diagram with OEM Numbers & Prices | EPC Data
