REAR DISC BRAKE CALIPER & DUST COVER

04466PAD KIT, DISC BRAKE, REAR

main04466-30210iGRS182200411-200509

MARK AK PA561H

main04466-30230iGRS182200509-200802

MARK AK NS254

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-30340iGRS182200411-200511

sub04479-30550

main04479-30450iGRS182200511-200709

sub04479-30510

main04479-30510iGRS182200709-200802

sub04479-53070

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04946-30110iGRS182200411-200802

04948FITTING KIT, DISC BRAKE, REAR

main04948-30090iGRS182200411-200511

sub04948-30140

main04948-30140iGRS182200511-200705

sub04948-30220

main04948-30220iGRS182200705-200802

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010iGRS182200411-200802

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-27030iGRS182200411-200802

47730BCYLINDER ASSY, REAR DISC BRAKE, RH

main47830-30300iGRS182200411-200511

sub47830-30301

main47830-30301iGRS182200511-200802

47731BPISTON, REAR DISC BRAKE

main47831-30300iGRS182200411-200802

47750ACYLINDER ASSY, DISC BRAKE, REAR LH

main47850-30300iGRS182200411-200511

sub47850-30301

main47850-30301iGRS182200511-200802

47769ABUSH, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47879-30300iGRS182200411-200802

47775DBOOT, BUSH DUST(FOR REAR DISC BRAKE)

main47775-32050iGRS182200411-200511

main47875-22221iGRS182200511-200707

sub47875-30340

main47875-30340iGRS182200707-200802

sub47875-30341

47795APLATE, REAR DISC BRAKE CALIPER, NO.1

main47895-30300iGRS182200411-200802

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90105-10525iGRS182200411-200802

47814PIN, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47814-30300iGRS182200411-200802

47815PIN, REAR CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)

main47815-30300iGRS182200411-200511

47843CLIP, REAR DISC BRAKE PIN HOLD

main47843-30300iGRS182200411-200705

16 parts on this diagram · 1 diagram in section
