CLUTCH & RELEASE FORK

31126BOOT, CLUTCH RELEASE FORK

main31126-22050iJZS155..5F199512-199909

31204FORK SUB-ASSY, CLUTCH RELEASE

main31204-22050iJZS155..5F199512-199909

31210COVER ASSY, CLUTCH

main31210-30261iJZS155..5F199512

sub31210-30262

31230BEARING ASSY, CLUTCH RELEASE

main31230-22100iJZS155..5F199512-199909

sub31230-22101

31232ACLIP, RELEASE BEARING HUB

main31232-22020iJZS155..5F199512-199909

TYPE A:REFER TO ILLUSTRATION

31236BSUPPORT, RELEASE FORK

main31236-14010iJZS155..5F199512-199909

31250DISC ASSY, CLUTCH

main31250-30390iJZS155..5F199512-199901

sub31250-30391

main31250-30391iJZS155..5F199901

33311WBEARING (FOR INPUT SHAFT)

main90363-12002iJZS155..5F199512

sub90363-12024

9011908026

main90119-08026

9 parts on this diagram · 1 diagram in section
