BRAKE PEDAL & BRACKET

47101PEDAL SUB-ASSY, BRAKE

main47101-30270iGS131,LS130,MS132,133..RHD..MTM198709-199110

main47101-30280iGS131,MS13#..RHD..ATM198709-199110

main47101-30290iGS131,LS130,MS132,133,YS132..LHD..MTM198709-199110

main47101-30300iMS13#..LHD..4FC198709-199110

47101ASPRING(FOR BRAKE PEDAL RETURN)

main90506-12055iGS131,LS130,MS13#,YS132198709-199110

main90507-12039iGS131,LS130,MS133,135..RHD198908-199110

47101BBUSH(FOR BRAKE PEDAL)

main90386-13015iGS131,LS130,MS13#,YS132198709-199110

47121PAD, BRAKE PEDAL

main31321-14020iGS131,LS130,MS132,133,YS132..MTM198709-199110

main47121-14010iGS131,MS13#..ATM198709-199110

47124SHAFT, BRAKE PEDAL

main90101-10164iGS131,LS130,MS13#..RHD198709-199110

main90101-10480iGS131,LS130,MS13#,YS132..LHD198709-199110

sub91552-81090

47124ACOLLAR(FOR BRAKE PEDAL SHAFT)

main90387-10105iGS131,LS130,MS13#..RHD198709-199110

main90387-10128iGS131,LS130,MS13#,YS132..LHD198709-199110

47131CUSHION(FOR STOP LAMP SWITCH)

main90541-06032iGS131,LS130,MS13#,YS132198709-199110

sub90541-06036

47264APIN(FOR PUSH ROD)

main90249-10064iGS131,LS130,MS13#,YS132198709-199110

55106SUPPORT SUB-ASSY, BRAKE PEDAL

main55106-30170iGS131,LS130,MS13#..RHD198709-199110

main55106-30200iGS131,MS13#..LHD..(ROY,SAL,SALEX)198709-199110

sub55106-30210

main55106-30210iLS130,MS132,YS132..LHD..(DLX,STD)198709-199110

9046816142

main90468-16142

9165160822

main91651-60822

9411051000

main94110-51000

9451201000

main94512-01000

13 parts on this diagram · 1 diagram in section
