FRONT BUMPER & BUMPER STAY

0001 1 0002 1 0003 1

52021REINFORCEMENT SUB-ASSY, FRONT BUMPER

main52021-22220iMX81,RX8#..V198808-199608

main52021-22230iGX81,LX80,MX8#,RX8#..ARL,GEN198808-199008

main52021-22260iGX81,LX80,MX83,RX80199008-199302

52115ASUPPORT, FRONT BUMPER SIDE, RH

main52115-22140iMX81,RX81198808-199608

main52115-22160iGX81,LX80,MX83,RX80199008-199302

52116ASUPPORT, FRONT BUMPER SIDE, LH

main52116-22120iGX81,LX80,MX8#,RX8#198808-199608

main52116-22130iGX81,LX80,MX83,RX80199008-199302

52119ACOVER, FRONT BUMPER

main52119-22360iLX80,RX80199008-199302

main52119-22380-05iGX81,MX83199008-199302

BEIGE M.M/GRAY M.M,4J1

main52119-22550iLX80,MX83,RX8#..(GL,XL)..(ARL,GEN)198808-199008

sub52119-22917

main52119-22620iMX81,RX8#..(GL,XL)..V198808-199608

main52119-22917iLX80,RX8#..GEN198808-199008

W/O(PAINTED)

main52119-22918iMX81..GD198808-199302

W(PAINTED COLLOR BUMPER)

main52119-22918iRX81..GL199302-199608

main52119-22922iLX80,RX80199008-199302

W(PAINTED COLLOR BUMPER)

52521RETAINER, FRONT BUMPER, UPPER CENTER

main52521-22100iGX81,LX80,MX8#,RX8#198808-199608

52525RETAINER, FRONT BUMPER, LOWER CENTER

main52525-22020iMX81,RX8#..V198808-199608

main52525-22060iGX81,LX80,MX8#,RX8#..ARL,GEN198808-199008

main52525-22070iGX81,LX80,MX83,RX80199008-199302

52526RETAINER, FRONT BUMPER, LOWER SIDE

main52526-22011iMX81,RX8#..V198808-199608

main52526-22060iGX81,LX80,MX8#,RX8#..ARL,GEN198808-199008

main52526-22070iGX81,LX80,MX83,RX80199008-199302

52535RETAINER, FRONT BUMPER SIDE, RH

main52535-22010iGX81,LX80,MX83,RX80199008-199302

main52535-22020iGX81,LX80,MX8#,RX8#198808-199608

52536RETAINER, FRONT BUMPER SIDE, LH

main52536-22010iGX81,LX80,MX83,RX80199008-199302

main52536-22020iGX81,LX80,MX8#,RX8#198808-199608

52611ABSORBER, FRONT BUMPER ENERGY

main52611-22110iGX81,LX80,MX8#,RX8#..ARL,GEN198808-199008

main52611-22130iMX81,RX8#..V198808-199608

main52611-22150iGX81,LX80,MX83,RX80199008-199108

sub52611-22151

main52611-22151iGX81,LX80,MX83,RX80199108-199302

52677SUPPORT, FRONT BUMPER SIDE, NO.2, RH

main52677-22010iGX81,LX80,MX8#,RX8#198808-199608

52678SUPPORT, FRONT BUMPER SIDE, NO.2, LH

main52677-22010iMX81,RX81198808-199608

52711MOULDING, FRONT BUMPER

main52711-22050iGX81,LX80,MX8#,RX8#..ARL,GEN198808-198904

BLACK

sub52711-22051

main52711-22051iGX81,LX80,MX8#,RX8#..ARL,GEN198904-199008

BLACK

main52711-22100iMX81,RX80..V198808-198904

sub52711-22101

main52711-22101iMX81,RX8#..V198904-199008

main52711-22140iGX81,LX80,MX83,RX80199008-199203

sub52711-22141

main52711-22141iGX81,LX80,MX83,RX80199203-199302

main52711-22170iMX81,RX81199008-199104

sub52711-22171

main52711-22171iMX81,RX81199104-199608

9011906136

main90119-06136

9011910192

main90119-10192

9015960213

main90159-60213

9016840094

main90168-40094

9017906007

main90179-06007

9018904069

main90189-04069

9046705066

main90467-05066

904670703001

main90467-0703001

9046709029

main90467-09029

9046804079

main90468-04079

9046804139

main90468-04139

24 parts on this diagram · 3 diagrams in section
