SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE & TRANSMISSION 0004 1ENGINE ROOM RELAY BLOCK 0005 1ENGINE ROOM RELAY BLOCK 0006 1COWL 0007 1COWL 0008 1INTRUMENT PANEL 0009 1INTRUMENT PANEL 0010 1CONSOLE BOX 0011 1CONSOLE BOX 0012 1STEERING 0013 1SEAT 0014 1SEAT 0015 1DOOR 0016 1DOOR 0017 1FLOOR & LUGGAGE 0018 1FLOOR & LUGGAGE

82715BRACKET,WIRING HARNESS CLAMP

main82715-06X30iAXVA80,AXVH80,MXVA80202410

82715WBRACKET, WIRING HARNESS CLAMP

main82715-12V90iMXVA80202410

main82715-33K11iAXVA80,AXVH80202410

84540SWITCH ASSY, NEUTRAL START

main84540-33021iAXVA80202410

89422ASENSOR, WATER TEMPERATURE

main89422-33040iAXVA80,AXVH80,MXVA80202410

89467BSENSOR, AIR FUEL RATIO

main89467-33350iAXVA80,AXVH80202410

main89467-47040iMXVA80202410

89467CSENSOR, AIR FUEL RATIO, NO.2

main89467-33360iAXVA80,AXVH80,MXVA80202410

89615SENSOR, KNOCK CONTROL

main89615-20090iAXVA80,AXVH80,MXVA80202410

90119T0260

main90119-T0260

90178T0018

main90178-T0018

9046814044

main90468-14044

9155180835

main91551-80835

9165340625

main91653-40625

9415180600

main94151-80600

13 parts on this diagram · 18 diagrams in section
