REAR DISC BRAKE CALIPER & DUST COVER

04466PAD KIT, DISC BRAKE, REAR

main04466-06230iAXVH80,MXVA80,MXVH80202403

MARK AK NS554

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-06370iAXVH80,MXVA80,MXVH80202403

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04946-06180iAXVH80,MXVA80,MXVH80202403

04948FITTING KIT, DISC BRAKE, REAR

main04948-02170iAXVH80,MXVA80,MXVH80202403

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-0N010iAXVH80,MXVA80,MXVH80202403

4601

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-20010iAXVH80,MXVA80,MXVH80202403

47721DBOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)

main90016-AA612iAXVH80,MXVA80,MXVH80202403

47769ABUSH, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47769-0P010iAXVH80,MXVA80,MXVH80202403

47803COVER SUB-ASSY, DISC BRAKE DUST, REAR RH

main47803-06030iAXVH80,MXVA80,MXVH80202403

47804COVER SUB-ASSY, DISC BRAKE DUST, REAR LH

main47804-06030iAXVH80,MXVA80,MXVH80202403

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90105-C0255iAXVH80,MXVA80,MXVH80202403

47814PIN, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47814-06180iAXVH80,MXVA80,MXVH80202403

47815PIN, REAR CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)

main47815-06180iAXVH80,MXVA80,MXVH80202403

47821MOUNTING, REAR DISC BRAKE CYLINDER, RH

main47821-06180iAXVH80,MXVA80,MXVH80202403

47822MOUNTING, REAR DISC BRAKE CYLINDER, LH

main47822-06170iAXVH80,MXVA80,MXVH80202403

47830CYLINDER ASSY, DISC BRAKE, REAR RH

main47830-06230iAXVH80,MXVA80,MXVH80202403

47831PISTON, REAR DISC BRAKE

main47831-07030iAXVH80,MXVA80,MXVH80202403

main47831-78010iAXVH80,MXVA80,MXVH80202403

47850CYLINDER ASSY, DISC BRAKE, REAR LH

main47850-06220iAXVH80,MXVA80,MXVH80202403

19 parts on this diagram · 1 diagram in section
