SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE & TRANSMISSION 0004 1ENGINE & TRANSMISSION 0005 1ENGINE ROOM 0006 1ENGINE ROOM RELAY BLOCK 0007 1ENGINE ROOM RELAY BLOCK 0008 1COWL 1/2 0009 1COWL 2/2 0010 1INSTRUMENT PANEL 0011 1STEERING 0012 1SEAT 0013 1DOOR,FLOOR & LUGGAGE

83520GAGE ASSY,OIL PRESSURE SENDER

main83520-33010iAXVA70,AXVH71201712-202103

main83520-60060iASV71201712-201902

84540SWITCH ASSY, NEUTRAL START

main84540-12240iMXVA71201903-202304

main84540-33010iASV71201712-201902

main84540-33020iAXVA70201712-202202

sub84540-33021

sub35572-48051

main84540-33021iAXVA70202202

89429FSENSOR, TEMPERATURE

main89429-12010iAXVA70,AXVH71201712-202103

89465SENSOR, OXYGEN

main89465-06300iASV71201712-201902

89467BSENSOR, AIR FUEL RATIO

main89467-06220iASV71201712-201902

main89467-06270iAXVA70,AXVH71201712-202304

main89467-0R160iMXVA71202304

main89467-0R190iAXVA70,AXVH71202304

main89467-F4010iMXVA71201903-202304

89491SENSOR, ENGINE OIL LEVEL

main89491-33040iASV71201712-201808

sub89491-33042

main89491-33042iASV71201809-201902

main89491-33050iAXVA70,AXVH71201712-201805

sub89491-33051

main89491-33051iAXVA70,AXVH71201806-202304

sub89491-33052

main89491-33052iAXVA70,AXVH71202205

89615SENSOR, KNOCK CONTROL

main89615-20090iAXVA70,AXVH71,MXVA71201712-202103

827150X090BRACKET,WIRING HARNESS CLAMP

main82715-0X090

90105C0048

main90105-C0048

90119C0098

main90119-C0098

90119C0100

main90119-C0100

9043012221

main90430-12221

9046815007

main90468-15007

9046906005

main90469-06005

9155180835

main91551-80835

9165140620

main91651-40620

16 parts on this diagram · 13 diagrams in section
