REAR DISC BRAKE CALIPER & DUST COVER

04466PAD KIT, DISC BRAKE, REAR

main04466-06230iAXVA70,AXVH71,MXVA71201712-202103

MARK AK NS554

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-06370iASV71201712-202103

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04946-06150iAXVA70,AXVH71,MXVA71201712-202103

04948FITTING KIT, DISC BRAKE, REAR

main04948-02170iAXVA70,AXVH71,MXVA71202102-202103

main04948-06060iASV71,AXVA70,AXVH71,MXVA71201712-202101

sub04948-02170

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-0N010iASV71201712-202103

4601

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-20010iASV71201712-202103

47721DBOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)

main90016-AA612iASV71201712-202103

47769ABUSH, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47769-0P010iASV71201712-202103

47775DBOOT, BUSH DUST(FOR REAR DISC BRAKE)

main47875-06180iASV71,AXVA70,AXVH71,MXVA71201712-202103

47803COVER SUB-ASSY, DISC BRAKE DUST, REAR RH

main47803-06030iASV71201712-202103

47804COVER SUB-ASSY, DISC BRAKE DUST, REAR LH

main47804-06030iASV71201712-202103

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90105-C0255iAXVA70,AXVH71,MXVA71201712-202103

47814PIN, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47814-06180iASV71201712-202103

47815PIN, REAR CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)

main47815-06180iASV71201712-202103

47821MOUNTING, REAR DISC BRAKE CYLINDER, RH

main47821-06180iASV71201712-202103

47822MOUNTING, REAR DISC BRAKE CYLINDER, LH

main47822-06170iAXVA70,AXVH71,MXVA71201712-202103

47830CYLINDER ASSY, DISC BRAKE, REAR RH

main47830-06180iAXVA70,AXVH71,MXVA71201712-202103

47831PISTON, REAR DISC BRAKE

main47831-06180iAXVA70,AXVH71,MXVA71202006-202302

(L)

main47831-06180iASV71201712-202006

main47831-07030iAXVA70,AXVH71,MXVA71202302

(L)

main47831-78010iAXVA70,AXVH71,MXVA71202006-202103

(J)

47850CYLINDER ASSY, DISC BRAKE, REAR LH

main47850-06170iASV71201712-202103

20 parts on this diagram · 1 diagram in section
