RADIO RECEIVER & AMPLIFIER & CONDENSER

86011ACONDENSER, RADIO SETTING

main90980-04023iAT160,ST162..LHD198508-198708

DEFOGGER

sub90980-04043

main90980-04041iAT160,ST162,182198508-198708

IG COIL

main90980-04062iAT160,ST162,182..RHD198508-198708

DEFOGGER

86011CFILTER, NOISE

main90980-05073iAT160,ST162,182198508-198708

86120RECEIVER ASSY, RADIO

main86120-14392iAT160,ST162..GEN,ME198508-198708

SW/MW

main86120-14421iAT160,ST162..GEN198508-198708

AM

sub86120-10260

sub86203-20180

main86120-14431iAT160..CBR198508-198708

AM/FM MONO

main86120-14461iAT160,ST162..GEN,ME198508-198708

AM/FM MPX 5PB

sub86120-16430

sub86203-20180

main86120-14680iAT160198601-198708

*20

main86120-20580iAT160,ST162..GEN198508-198708

*17

main86120-20590iAT160,ST162..GT198508-198708

MW/SW/FM ELECTRONIC SEARCH

86120AKNOB, RADIO RECEIVER SWITCH

main86128-14580iAT160,ST162,182198508-198708

AM,AM/FM OR SW/MW,EXCL/*17

86120BKNOB, RADIO RECEIVER TUNING, NO.1

main86128-14580iAT160,ST162,182198508-198708

AM,AM/FM OR SW/MW,EXCL/*17

86120DKNOB, RADIO RECEIVER TONE

main86128-14600iAT160,ST162,182198508-198708

AM,AM/FM OR SW/MW,EXCL/*17

86120EKNOB, RADIO RECEIVER BALANCE

main86128-14600iAT160,ST162,182198508-198708

AM/FM MPX,EXCL/*17

86120HKNOB, RADIO RECEIVER SELECT

main86128-14700iAT160,ST162..GEN,ME198508-198708

SW/MW

86211BRACKET, RADIO, NO.1

main86211-20150iAT160,ST162,182198508-198708

86212BRACKET, RADIO, NO.2

main86212-20190iAT160,ST162,182198508-198708

86260TAPE PLAYER ASSY

main86260-14271iAT160,ST162..GEN,ME198610-198708

W/2 SPEAKERS

main86260-19045iAT160,ST162,182198508-198610

W/2 SPEAKERS

sub86260-14270

main86260-20160iAT160,ST162..GEN,ME198508-198708

W/4 SPEAKERS

86280AMPLIFIER ASSY, STEREO COMPONENT

main86280-14190iAT160198601-198708

RADIO;*20

9011906005

main90119-06005

9014950032

main90149-50032

9015950173

main90159-50173

9098004023

main90980-04023

9098004041

main90980-04041

9098004062

main90980-04062

18 parts on this diagram · 1 diagram in section
