SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE & TRANSMISSION 0004 1ENGINE & TRANSMISSION 0005 1ENGINE ROOM 0006 1ENGINE ROOM 0007 1ENGINE ROOM 0008 1ENGINE ROOM 0009 1ENGINE ROOM 0010 1ENGINE ROOM 0011 1ENGINE ROOM 0012 1ENGINE ROOM 0013 1ENGINE ROOM RELAY BLOCK 0014 1ENGINE ROOM RELAY BLOCK 0015 1ENGINE ROOM RELAY BLOCK 0016 1ENGINE ROOM RELAY BLOCK 0017 1ENGINE ROOM RELAY BLOCK 0019 1COWL 0020 1COWL 0021 1COWL 0022 1COWL 0023 1INSTRUMENT PANEL 1/2 0024 1INSTRUMENT PANEL 1/2 0025 1INSTRUMENT PANEL 1/2 0026 1INSTRUMENT PANEL 1/2 0027 1INSTRUMENT PANEL 2/2 0028 1INSTRUMENT PANEL 2/2 0029 1INSTRUMENT PANEL 2/2 0030 1INSTRUMENT PANEL 2/2 0031 1STEERING 0032 1SEAT 0033 1DOOR & ROOF 0034 1DOOR & ROOF 0035 1FLOOR & LUGGAGE 0036 1FLOOR & LUGGAGE

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-28020iAVE30,GSE31¥1,970201304-202309

DENSO,*369

main83530-60020iAVE30,GSE31¥1,970201304-202309

YAZAKI,*369

89451ASENSOR, SHIFT LEVER POSITION

main89451-30010iAVE30¥6,500201304-202110

89465SENSOR, OXYGEN

main89465-30730iGSE3#¥9,400201304-201308

main89465-30B40iGSE31¥6,400201710-202310

main89465-53250iAVE30¥6,400201304-202110

main89465-53270iGSE31¥9,400201308-201710

main89465-53310iASE30¥6,400201508-202110

89467BSENSOR, AIR FUEL RATIO

main89467-22030iGSE3#¥9,900201304-201710

main89467-30060iAVE30¥9,900201304-202110

main89467-30080iGSE31¥9,900201710-202309

main89467-53090iASE30¥9,900201508-202110

89491SENSOR, ENGINE OIL LEVEL

main89491-30061iGSE31¥9,500201304-201710

main89491-30080iASE30,AVE30¥7,200201304-202110

main89491-30100iGSE31¥4,400201710-201808

sub89491-30101¥3,330

main89491-30101iGSE31¥3,330201809-202309

89491AGASKET, ENGINE OIL LEVEL SENSOR

main89493-60010iAVE30,GSE3#¥140201304-202110

89615SENSOR, KNOCK CONTROL

main89615-20090iGSE3#¥2,370201304-202310

8271530S60BRACKET,WIRING HARNESS CLAMP

main82715-30S60¥200

8271530S80BRACKET,WIRING HARNESS CLAMP

main82715-30S80¥450

9155180835

main91551-80835¥80

9165160614

main91651-60614¥70

91653A0620

main91653-A0620¥60

9167180612

main91671-80612¥60

13 parts on this diagram · 35 diagrams in section
