DISC WHEEL & WHEEL CAP
42601WHEEL, DISC
14X5.5J,TYPE C:REFER TO ILLUSTRATION
14X5.5J,TYPE D:REFER TO ILLUSTRATION
42601AWHEEL, DISC (FOR SPARE)
14X5.5J,TYPE D:REFER TO ILLUSTRATION
42611GVALVE (FOR TUBELESS TIRE)
42611JVALVE (FOR TUBELESS TIRE SPARE)
42652TIRE
185/65R14,*B/S,*D/L,*T/Y,*Y/H
155SR13
155SR13
175/70R13 82S
165SR13,*B/S,*D/L,*T/Y,*Y/H
165SR13,*Y/H
155/80R13
165SR13
175/70SR13,*B/S,*D/L,*T/Y,*Y/H
185/60R14 82H
175/70HR13,*Y/H
175/65R14
175/70HR13,*B/S,*D/L,*Y/H
42652ATIRE (FOR SPARE)
185/65R14
155SR13
155SR13
175/70R13 82S
165SR13,*B/S,*D/L,*T/Y,*Y/H
165SR13,*Y/H
155/80R13
165SR13
175/70SR13,*B/S,*D/L,*T/Y,*Y/H
185/60R14 82H
175/70HR13,*Y/H
175/65R14
175/70HR13,*B/S,*D/L,*Y/H
6 parts on this diagram · 4 diagrams in section
