REAR DISC BRAKE CALIPER & DUST COVER
04466PAD KIT, DISC BRAKE, REAR
MARK AK PA561
MARK AK PA511H
04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)
04948FITTING KIT, DISC BRAKE, REAR
31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)
47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)
47715CPIN, CYLINDER SLIDE(FOR REAR DISC BRAKE)
NO.1
NO.2
SUB
MAIN
MAIN
47721ECOLLAR(FOR REAR DISC BRAKE CYLINDER MOUNTING)
NO.2
NO.1
47730BCYLINDER ASSY, REAR DISC BRAKE, RH
47731CRING, SET(FOR REAR DISC BRAKE PISTON)
47743BSPRING, ANTI-RATTLE, NO.2(FOR REAR DISC BRAKE)
47748DSPRING, ANTI-RATTLE, NO.1(FOR REAR DISC BRAKE)
47748EPIN, W/HOLE(FOR REAR DISC BRAKE)
47748FCLIP(FOR REAR DISC BRAKE)
47750ACYLINDER ASSY, DISC BRAKE, REAR LH
17 parts on this diagram · 2 diagrams in section
