SUSPENSION CROSSMEMBER & UNDER COVER

0001 1 0005 1UNDER COVER 0008 1SUSPENSION CROSSMEMBER 0013 1

51201CROSSMEMBER SUB-ASSY, FRONT SUSPENSION

main51201-0D150iNCP15#..MA,VN201304-201703

sub51201-0D151

main51201-0D151iNSP150,151..VN201704-202406

main51201-0D170iNCP150..TAIW201404-201411

main51201-0D171iNSP151..TAIW201412-202101

main51201-0D180iNSP151..5F..D..C;NSP150..CVT..D..C;NSP150,151..(G,R)..C201312-202207

main51201-0D240iNSP151..CVT..H201807-201910

main51201-0D250iNSP151..6F..H201807-201910

51405ACOVER SUB-ASSY, ENGINE UNDER, NO.1

main51405-0D041iNSP150..CVT..GEN;NSP151..LHD..GEN..A;NSP150..LHD..5F..GEN201710-202207

ROUGH ROAD AREA SPEC-ENGINE UNDER COVER=STEEL,WITH(HEIGHT UP)

51441CCOVER, ENGINE UNDER, RH

main51441-0D280iNSP151..MA201304-202207

main51441-0D310iNSP150,151..D201307-201910

main51441-0D320iNSP151..TAIW201404-202101

main51441-0D330iNSP150..C;NSP151..(D,R)..C;NSP151..(GCC,IDN)..G..C201312-202207

main51441-0D370iNSP150,151..I202003-202406

main51441-0D431iNSP151..G201804-201908

main51441-0D500iNSP151..H201807-201910

51441KGROMMET(FOR ENGINE UNDER COVER)

main90189-06006iNSP151..F201304-202104

main90189-06006iNSP150..5F..G..A;NSP150..5F..GCC..D..A202102-202207

(J)

main90189-06076iNSP151..6F..H;NSP152..HTWCB201807-202207

main90189-T0022iNSP150..CVT..A;NSP151..LHD..GEN;NSP151..(GCC,TH)..A;NSP150..LHD..5F..GEN;NSP150..5F..GCC..R..A202102-202207

(L)

main90189-T0022iNSP150,151..I202104-202406

51442CCOVER, ENGINE UNDER, LH

main51442-0D170iNSP151..MA;NSP150..CVT..G..A;NSP151..LHD..GEN..A;NSP150..5F..GCC..R..A;NSP151..(GCC,TH,VN)..(A,E);NSP150..CVT..GCC..(D,R)..A;NSP150,152..(GEN,TH,VN)..(D,R)..(A,E)201304-202207

main51442-0D190iNSP150,151..D201307-201910

main51442-0D200iNSP151..TAIW201404-202101

main51442-0D210iNSP151..5F..D..C;NSP150..CVT..D..C;NSP150,151..(G,R)..C201312-202207

main51442-0D251iNSP151..G201804-201908

main51442-0D310iNSP151..H201807-201910

main51442-0D350iNSP150,151..I202003-202406

51451ACOVER, ENGINE UNDER, CENTER

main51451-0D030iNSP150..CVT..GEN;NSP151..LHD..GEN..A;NSP150..LHD..5F..GEN201710-202207

ROUGH ROAD AREA SPEC-ENGINE UNDER COVER=STEEL,WITH(HEIGHT UP)

51451DSCREW, NO.1

main90159-60383iNSP151..RHD..GEN201710-202207

ROUGH ROAD AREA SPEC-ENGINE UNDER COVER=STEEL,WITH(HEIGHT UP),(J)

main90159-60383iNCP150,NSP151..TAIW201404-201802

main90159-60383iNSP151..F201708-202406

(J)

main90159-T0008iNCP15#,NSP150,151..(GCC,GEN,IDN,MA,PH,TH,VN)..(B,C)201304

main90159-T0008iNSP151..RHD..GEN201710-202207

ROUGH ROAD AREA SPEC-ENGINE UNDER COVER=STEEL,WITH(HEIGHT UP),(L)

main90159-T0008iNSP150..CVT..GEN;NSP151..LHD..GEN..A;NSP150..LHD..5F..GEN201708-202406

(L)

51451ESCREW, NO.2

main90159-60488iNCP150,NSP151..TAIW201404-201910

main90159-T0033iNSP151..F201304-202406

51451JBOLT, NO.1

main90119-06767iNSP150..CVT..GEN;NSP151..LHD..GEN..A;NSP150..LHD..5F..GEN201710-202207

ROUGH ROAD AREA SPEC-ENGINE UNDER COVER=STEEL,WITH(HEIGHT UP),(J)

main90119-06767iNCP150,NSP151..TAIW201404-202101

main90119-06767iNSP150..5F..G..A;NSP151..CVT..D..C;NSP150..5F..GCC..D..(A,C)201708-202207

(J)

main90119-T0144iNSP150..CVT..GEN;NSP151..LHD..GEN..A;NSP150..LHD..5F..GEN201710-202207

PERU SPEC

main90119-T0144iNSP150..CVT..GEN;NSP151..LHD..GEN..A;NSP150..LHD..5F..GEN201710-202207

MEXICO SPEC&ROUGH ROAD AREA SPEC-ENGINE UNDER COVER=PLASTIC, W(HEIGHT UP)

main90119-T0144iNCP15#,NSP150,151..(GCC,GEN,IDN,MA,PH,TH,VN)..(B,C)201304-202406

main90119-T0144iNSP150,151..LHD..5F..GEN..(G,R)201710-202207

LATIN AMERICA SPEC

main90119-T0144iNSP150,151..LHD..5F..GEN..(G,R)201710-202207

CHILE SPEC

main90119-T0144iNSP150,151..LHD..5F..GEN..(G,R)201710-202207

ECUADOR SPEC&ROUGH ROAD AREA SPEC-ENGINE UNDER COVER=PLASTIC, W(HEIGHT UP)

main90119-T0144iNSP150,151..LHD..5F..GEN..(G,R)201708-202207

(L)

main90119-T0144iNSP150,151..LHD..5F..GEN..(G,R)201710-202207

ROUGH ROAD AREA SPEC-ENGINE UNDER COVER=STEEL,WITH(HEIGHT UP),(L)

5201

7601

9011912389

main90119-12389

9011912391

main90119-12391

90119T0351

main90119-T0351

90119T0352

main90119-T0352

9046710216

main90467-10216

90467T0049

main90467-T0049

17 parts on this diagram · 4 diagrams in section
