REAR OIL PUMP & GOVERNOR (ATM)

0001 1A131L 0002 1A240L

35145AADAPTER, GOVERNOR PRESSURE

main35145-32011iAL50..3FC199612-199810

35145BSPRING, TORSION(FOR GOVERNOR PRESSURE ADAPTER)

main90508-18034iAL50..3FC199612-199810

35149COVER, GOVERNOR

main35149-12010iAL50..3FC199612-199810

main35149-20010iAL50..4FC199810-200307

35149ARING, O (FOR GOVERNOR COVER)

main90301-68001iAL50..4FC199810-200307

main90301-73001iAL50..3FC199612-199810

35157AADAPTER, GOVERNOR BODY

main35157-12010iAL50..3FC199612-199810

main35157-20031iAL50..4FC199810-200307

35188ABRACKET, GOVERNOR COVER

main35188-12010iAL50..3FC199612-199810

main35188-20010×2iAL50..4FC199810-200307

35189WASHER, GOVERNOR THRUST, NO.1

main35189-32011iAL50..ATM199612-200307

35480FBODY ASSY, GOVERNOR

main35480-16050iAL50..4FC199810-200307

main35480-32013iAL50..3FC199612-199810

35480GWASHER, PLATE (FOR GOVERNOR BODY)

main90201-25003iAL50..3FC199612-199810

35779GEAR, GOVERNOR DRIVE

main35779-32010iAL50..3FC199612-199810

9165140816

main91651-40816

11 parts on this diagram · 2 diagrams in section
