RADIO RECEIVER & AMPLIFIER & CONDENSER

0001 1 0002 1W(SIDE PANEL) 0003 1CONDENSER

86120RECEIVER ASSY, RADIO

main86120-16650iNCP1#..GEN199908-200208

MATSUSHITA, ID=52201,TYPE C:REFER TO ILLUSTRATION

main86120-16680iNCP1#..GCC,GEN200208-200512

MATSUSHITA, ID=57206,TYPE B:REFER TO ILLUSTRATION

main86120-2B610iNCP1#199908-200208

FUJITSU TEN,ID=17411,TYPE D:REFER TO ILLUSTRATION

main86120-2B620iNCP1#..GEN200208-200512

MATSUSHITA,ID=57410,TYPE E:REFER TO ILLUSTRATION

main86120-2B680iNCP1#..GEN199908-200208

TYPE A:REFER TO ILLUSTRATION

86211BRACKET, RADIO, NO.1

main86211-52010iNCP1#199908-200208

main86211-52140iNCP1#..RHD200208

86212BRACKET, RADIO, NO.2

main86212-52010iNCP1#199908-200208

main86212-52130iNCP1#..RHD200208

8612835010KNOB, RADIO RECEIVER

main86128-35010

8612835050KNOB, RADIO RECEIVER

main86128-35050

9015350010

main90153-50010

9015950372

main90159-50372

7 parts on this diagram · 3 diagrams in section
