FRONT FENDER APRON & DASH PANEL

0001 1 0002 1 0003 1RHD 0004 1LHD 0005 1

5201

5302

53028SUPPORT SUB-ASSY, RADIATOR, LOWER

main53028-WC003

5303

53202DCUSHION, RADIATOR SUPPORT

53205SUPPORT SUB-ASSY, RADIATOR, UPPER

main53205-WC004

53245BRACKET, HEADLAMP, RH

main53245-WC001

53246BRACKET, HEADLAMP, LH

main53246-WC001

5503

57151REINFORCEMENT, FRONT SIDE MEMBER, NO.1

main57151-WC002

57152AREINFORCEMENT, FRONT SIDE MEMBER, NO.1 LH

90118WC022

main90118-WC022

90118WC044

main90118-WC044

90118WC222

main90118-WC222

14 parts on this diagram · 5 diagrams in section
